Good Quality Hydraulic Pipe Cutting Machine
- Shenzhen/GuangZhou
- T/T Credit Card
You May Like
Product Details
| Brand Name | Chine Chern | Place of Origin | Guangdong, China | |
| Model Number | JC-400-2AH | After-sales Service Provided | Overseas service center available |
Product Description
Semi automatic oil pressure pipe cutting machine features:
- Suitable for iron, steel ,stainless steel,carbon steel cutting
- Main shaft Blade penetrating and returning are very stable. Not easy to vibrate. Blades cutting route is not easy to change;
- Smooth and bright surface, high precision; hidden blade, safe upper and down work pieces
- Compared with common semiautomatic pipe cutting machines structural design, it is more advanced. This machine makes cutting work more accurate, more stable, quicker, and high-efficiency;
- Clamp arm and body are not easy to wear, guide rod is not easy to break and wear
- While cutting, work pieces don't move forward and backward, blades cutting are even, the saw blade is not easy to crack.
- Vertical chute feed type, it is more stablely when feeding the material. Long cutter life.
Special design, multiple sets of gears are applying for heavy-duty cutting. High precision
The structure of the machine is stable and solid, long lifespan.
Automatic cooling fluid circulation, to ensure a smooth workpiece section
Cutting focus, simple and easy to maintain.
Technical parameters:
| Model | JC-400-2AH(3#) | |
| Head rotating angle | 90° | 45° |
| Round tube | 130mm | 110mm |
| Square tube | 120mm*120mm | 100mm*100mm |
| Rectangular tube | 160mm*80mm | 110mm*100mm |
| Solid round bar | 70mm | 60mm |
| Solid square bar | 75mm*75mm | 60mm*60mm |
| Host motor | 3P/6HP 2.2KW | |
| Spindle speed(RPM) | 72/32 55/22 | |
| Cooling pump | 1/8HP Automatic circulation cooling | |
| Hydraulic motor | 2.2LW/4 Pole work pressure 25-35kg/cm2 | |
| Suitable saw blade diameter | 250mm-400mm,bore 32mm | |
| Machine size | L1200*W900*H1980mm | |
| Machine weight | 680kg | |
WHY CHOOSE US?
Chine Chern is a top and professional high-tech enterprise with more than 20 years of manufacturing experience. We are fully committed to producing technologically advanced pipe processing machines, such as pipe cutting machines, pipe bending machines, aluminum cutting machines, chamfering machines, etc. We have partnered with leading operators and manufacturers in the industry, including BYD and some other famous customers at home and abroad. We also set up our branch office in Taiwan. In addition, we are authorized by Taiwan Eyan Machine Tool to be their main distributor in China.
Our focus is on R&D, ensuring that we provide our customers with top-quality and innovative products. In addition, we use stringent quality control measures to ensure the reliability of our products. With sound business credit, excellent after-sales service, and modern manufacturing facilities, we have earned an excellent reputation among our customers across the globe.
We emphasize development, and introduce new products into the market every year. Our products sell well in domestic and international markets, such as India, Malaysia and South Africa, and are favorably appraised by clients. We pursue the management tenet of "Quality is superior, Service is supreme, and Reputation is first", and will sincerely create and share success with all clients.
We welcome you to contact us for more information and look forward to working with you! We will be a reliable and strong supplier in China.
Sections:
Details:
Packing:
Certificate :
Company Profiles :
with decades hard work and accumulated experiences, We have acquired fourty invention
patent,Utility model and appearance patent.Meanwhile, We have passed ISO9001:2008 quality system certificate, Government-issued Guangdong Province private technology enterprises, high-
tech enterprises, private enterprises and other honors.
The products include Super hard metal bar cold saw machine series, Chipless metal pipes circular saw machine series,Copper aluminum non-ferrous high-speed precision circular saw machine series,Metal pipe/bar end chamfer machine series,Circular saw blade sharpening machine series,Automatic pipe bending and forming Machine series , Six categories eighty models , Also provide customized complex process
Machine , all kinds of circular saw blade . Wide Application range contains Nautical
aviation and aerospace industry, military industry, high-speed rail and rail transportation
industry, auto industry, precision parts, medical and fitness equipment industry, mechanical and electrical and electronic industry, lighting and furniture decoration forty industries .
