Home > Products > Industrial Elevators > Frequency Conversion Industrial elevators 3200kg High Capacity for Bridge Engineering
Frequency Conversion Industrial elevators 3200kg High Capacity for Bridge Engineering
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Construction Material Lift Equipment Hoisting Machine for transporting passenger
-
Single Car Industrial Elevators , Building Lifter CH160 with 118 Mast Section
-
Single Car 300kg Capacity Industrial Elevators CH300 with Mast Hot-dip Galvanized
-
Mast Single Cage Hoists Lift for Heavy Materials or Passenger , Builder Hoist SC 200
-
High performance Single Cage Hoists 1000kg Building Material Hoisting Equipment
-
Durable Building Material Hoist / Construction Site Elevator High Reliability
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | CH-series |
Product Description
Certification:CE,ISO
Frequency Conversion Industrial elevators CH 320 Single Car With 3200kg Capacity
Quick Detail:
|
Name |
Other Name |
Brand Name |
Control |
|
Industrial elevators |
Industrial elevators CH 3200 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
3200kg |
Certificate |
CE |
DeCription:
Industrial elevators CH 3200 is installed and dismounted conveniently and can grow as high as the building grows height.The Industrial elevators has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
Applications:
CH serialization of products Industrial elevators is a Rack and Pinion EL. Industrial elevators widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.
Specifications
Standard technical datas of single car :
|
Parameter |
CH1000 |
CH1600 |
CH2000 |
CH2700 |
CH3200 |
|
Rated |
1000 |
1600 |
2000 |
2700 |
3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12 |
18 |
24 |
30 |
38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*9.5 |
2*11 |
2*13 |
3*18.5 |
3*22 |
|
Car inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Car weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4 |
SAJ50-2.0 |
|
Hanger rated lifting capacity |
250 |
250 |
250 |
250 |
250 |
|
Rack module |
8 |
8 |
8 |
8 |
8 |
CH series industrial elevators:
1). Car load capacity: 1000kg~3200kg;
2). Lifting speed:33m/min, 0~40m/min;0~60m/min;
3). Increased lifting height on request;
4). Mast section: Painted or hot dipped zinc
5). Car:double car
6). Recommended car inner dimensions (L*W*H): 3*1.3*2.5m, 3*1.4*2.5m, 3*1.5*2.5m, 3.2*1.5*2.5m, 3.6*1.5
