Home > Products > Construction Hoist Elevator > Red Double Cage Construction Material Electrical Hoist 380V 50Hz , Industrial Hoists
Red Double Cage Construction Material Electrical Hoist 380V 50Hz , Industrial Hoists
- T/T L/C D/P D/A
- 7 days
You May Like
-
Mast Hot-dip Galvanized , Painting Construction Hoist Elevator with Twin Cage 1600kg Capacity
-
Flexible Carrying 2 Rack Construction Material Lifting Hoist Vertical Transporting Equipment
-
12 - 38 Passenger or 1.6T Construction Material Lifting Hoist Equipment with CE
-
Durable Single Cage Building Construction Material Hoist Lift High Speed
-
VFD Construction Material Hoist Elevator / Building Hoisting Equipment 2700kg
-
Industrial Passenger Construction Material Hoist Elevator 2 Ton 0 ~ 60m/min
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | SC-series |
Product Description
Certification:CE,ISO
0 ~ 60 m / min Lifting Speed Construction Hoist El for Double Cage , 2700kg Capacity 380V 50Hz
Quick Detail:
|
Name |
Other Name |
Brand Name |
Control |
|
Construction lifting hoist |
Construction lifting hoist SC 270/270 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
2700kg/2700kg |
Certificate |
CE |
Description:
Construction lifting hoist SC 270/270 is installed and dismounted conveniently and can grow as high as the building grows height.The Construction lifting hoist has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
Applications:
SC serialization of products Construction lifting hoist is a Rack and Pinion EL. Construction lifting hoist widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.
Specifications
Standard technical datas of double cages:
|
Parameter |
SC100/100 |
SC160/160 |
SC200/200 |
SC270/270 |
SC320/320 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5 |
2*3*22 |
|
Cage inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Cage weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4 |
SAJ50-2.0 |
|
Hanger rated lifting capacity |
250 |
250 |
250 |
250 |
250 |
|
Rack module |
8 |
8 |
8 |
8 |
8 |
SC series construction lifting hoists:
1). Cage load capacity: 1000kg~3200kg;
2). Lifting speed:33m/min, 0~40m/min;0~60m/min;
3). Increased lifting height on request;
