Home > Products > Industrial Lift > Double Car Industrial Lift and Hoist for Building Site CH3200 3200kg Capacity 33 m/min
Double Car Industrial Lift and Hoist for Building Site CH3200 3200kg Capacity 33 m/min
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
2 Ton Safety Industrial Lift Conveyor Machine for transporting Construction Materials
-
Construction material hoisting equipment Industrial Lifter for Goods and Cargo
-
1 Ton Double Cage Industrial Lift High Safety and Flexible Carrying
-
Industrial Rack and Pinion Hoist Construction Material Lift Equipment 500kg
-
Single / Double Car 2700kg Industrial Elevators with Mast Hot-dip Galvanized
-
OEM Custom Industrial elevators / Cargo Lift for Construction Material and Passenger
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | CH-series |
Product Description
Certification:CE,ISO
Industrial hoists CH3200 Double Car 3200kg Capacity with Mast Hot-dip Galvanized
Quick Detail:
|
Name |
Other |
Brand Name |
Control |
|
Industrial hoists |
Industrial hoists CH 3200/3200 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
3200kg/3200kg |
Certificate |
CE |
Description:
Industrial hoists CH 3200/3200 is installed and dismounted conveniently and can grow as high as the building grows height.The Industrial hoists has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
Applications:
CH serialization of products Industrial hoists is a Rack and Pinion EL. Industrial hoists widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.
Specifications
Standard technical datas of double cars:
|
Parameter |
CH1000/1000 |
CH1600/1600 |
CH2000/2000 |
CH2700/2700 |
CH3200/3200 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5 |
2*3*22 |
|
Car inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Car weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4 |
SAJ50-2.0 |
|
Hanger rated lifting capacity |
250 |
250 |
250 |
250 |
250 |
|
Rack module |
8 |
8 |
8 |
8 |
8 |
CH series industrial hoists:
1). Car load capacity: 1000kg~3200kg;
2). Lifting speed:33m/min, 0~40m/min;0~60m/min;
3). Increased lifting height on request;
4). Mast section: Painted or hot dipped zinc
5). Car:double car
6). Rec
