VFC Control Rack and Pinion Building Site Hoist 2000kg Capacity with Mast Hot-dip Galvanized

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	BORUIDA		Place of Origin	China
Model Number	SC-series

Product Description

Delivery Time:25-35 days
Certification:CE,ISO

VFC Control Building Site Hoist SC 200 2000kg Capacity with Mast Hot-dip Galvanized

Quick Detail:

Name	Other Name	Brand Name	Control
Building Hoist	Building Hoist SC 200	BORUIDA	DOL and FC
Loading Capacity	2000kg	Certificate	CE

Description:

Building Hoist SC 200 is installed and dismounted conveniently and can grow as high as the building grows height.The Building Hoist has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment

Applications:

SC serialization of products Building Hoist is a Rack and Pinion EL. Building Hoist widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.

Specifications

Standard technical datas of single cage :

Parameter	SC100	SC160	SC200	SC270	SC320
Rated loading capacity (kg)	1000	1600	2000	2700	3200
Rated lifting speed (m/min)	0~40	0~40	0~60	0~60	0~60
Rated passenger number	12	18	24	30	38
Max. lifting height(m)	150	250	450	450	450
Engine power(kW)	2*9.5	2*11	2*13	3*18.5	3*22
Cage inner dimension (LWH)(m)	31.32.5	31.42.5	31.52.5	3.21.52.5	3.61.62.5
Cage weight (kg)	1400	1500	1800	1950	2050
Mast section weight (kg)	145	145	163	163	163
Mast section dimension (mm)	6506501508	6506501508	6506501508	6506501508	6506501508
Safety device type	SAJ30-1.2	SAJ40-1.2	SAJ40-1.4	SAJ40-1.4	SAJ50-2.0
Hanger rated lifting capacity (kg)	250	250	250	250	250
Rack module	8	8	8	8	8

SC series building hoists:

1). Cage load capacity: 1000
