1 Ton Double Cage Industrial Lift High Safety and Flexible Carrying

1 Ton Double Cage Industrial Lift High Safety and Flexible Carrying thumbnail-1
1 Ton Double Cage Industrial Lift High Safety and Flexible Carrying photo-1
Negotiable MOQ: 1 Kilogram (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
BORUIDA
Place of Origin:
China
Model Number:
CH-series
Contact Supplier Request Quote Chat Now
Wuxi Boruida Machinery Technologies Company
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BORUIDA
Place of Origin China
Model Number CH-series
Delivery Time:25-35 days
Certification:CE,ISO
Industrial Lift CH100 Double Cage 1000kg Capacity with Mast Hot-dip Galvanized



Quick Detail:


Name

Other Name

Brand Name

Control

Industrial hoists

Industrial hoists CH 1000/1000

BORUIDA

DOL and FC

Loading Capacity

1000kg/1000kg

Certificate

CE



Description:

Industrial hoists CH 1000/1000 is installed and dismounted conveniently and can grow as high as the building grows height.The Industrial hoists has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.It is efficient and safety vertical transporting equipment


Applications:

CH serialization of products Industrial hoists is a Rack and Pinion EL. Industrial hoists widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.


Specifications

Standard technical datas of  double cars:

Parameter

CH1000/1000

CH1600/1600

CH2000/2000

CH2700/2700

CH3200/3200

Rated
loading capacity
(kg)

1000/1000

1600/1600

2000/2000

2700/2700

3200/3200

Rated lifting speed
(m/min)

0~40

0~40

0~60

0~60

0~60

Rated passenger number

12/12

18/18

24/24

30/30

38/38

Max. lifting height(m)

150

250

450

450

450

Engine power(kW)

2*2*9.5

2*2*11

2*2*13

2*3*18.5

2*3*22

Car inner dimension
(L*W*H)(m)

3*1.3*2.5

3*1.4*2.5

3*1.5*2.5

3.2*1.5*2.5

3.6*1.6*2.5

Car weight (kg)

1400

1500

1800

1950

2050

Mast section weight
(kg)

145

145

163

163

163

Mast section dimension (mm)

650*650*1508

650*650*1508

650*650*1508

650*650*1508

650*650*1508

Safety device type

 SAJ30-1.2

SAJ40-1.2

SAJ40-1.4

SAJ40-1.4

SAJ50-2.0

Hanger rated lifting capacity
(kg)

250

250

250

250

250

Rack module

8

8

8

8

8

CH series industrial hoists:

1). Car load capacity: 1000kg~3200kg;

2). Lifting speed:33m/min, 0~40m/min;0~60m/min;

3). Increased lifting height on request;

4). Mast section: Painted or hot dipped zinc

5). Car:double car

6). Recommended car inn
