Lifting Speed 0 ~ 60m / min Industrial Lift CH 270 2700kg Capacity with Mast Hot-dip Galvanized
Quick Detail:
|
Name |
Other Name |
Brand Name |
Control |
|
Industrial hoists |
Industrial hoists CH 2700 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
2700kg |
Certificate |
CE |
DeCription:
Industrial hoists CH 2700 is installed and dismounted conveniently and can grow as high as the building grows height.The Industrial hoists has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.
It is efficient and safety vertical transporting equipment
Applications:
CH serialization of products Industrial hoists is a Rack and Pinion EL. Industrial hoists widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.
Specifications
Standard technical datas of single car :
|
Parameter |
CH1000 |
CH1600 |
CH2000 |
CH2700 |
CH3200 |
|
Rated |
1000 |
1600 |
2000 |
2700 |
3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12 |
18 |
24 |
30 |
38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*9.5 |
2*11 |
2*13 |
3*18.5 |
3*22 |
|
Car inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Car weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4 |
SAJ50-2.0 |
|
Hanger rated lifting capacity |
250 |
250 |
250 |
250 |
250 |
|
Rack module |
8 |
8 |
8 |
8 |
8 |
CH series industrial hoists:
1). Car load capacity: 1000kg~3200kg;
2). Lifting speed:33m/min, 0~40m/min;0~60m/min;
3). Increased lifting height on request;
4). Mast section: Painted or hot dipped zinc
5). Car:double car
6). Recommended car inner dimensions (L*W*H): 3*1.3*2.5m, 3*1.4*2.5m, 3*1.5*2.5m, 3.2*1.5*2.5m, 3.6*1
