Home > Products > Building Site Hoist > Red Painted Double Cage Building Site Hoist Equipment 1600kg , Building Materials Lift
Red Painted Double Cage Building Site Hoist Equipment 1600kg , Building Materials Lift
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Easy Install 1000kg 1 Ton Construction Material Lifting Hoist for Ship Industry
-
Frequency Conversion Passenger Hoist CH 2000 with Single Car 2000kg High Capacity
-
CH1000 Red 1000kg Material / Passenger Hoist With Single Cage , High Reliability
-
CE Approved Double Cage Passenger Hoist / Construction Lift Equipment 1600kg
-
Portable Construction Material Hoists / Passenger Hoist Green Yellow Or Customized
-
500kg High Capacity Passenger Hoists CH500 Single Car with Mast Hot-dip Galvanized
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | SC-series |
Product Description
Certification:CE,ISO
Red Painted Double Cage Building Site Hoist With 0 - 60m/min Wide Range Of Tie-in
Quick Detail:
|
Name |
other name |
Brand Name |
Control |
|
Building Hoist |
Building Hoist SC 160/160 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
1600kg/1600kg |
Certificate |
CE |
Description:
Building Hoist SC 160/160 is installed and dismounted conveniently and can grow as high as the building grows height.The Building Hoist has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.It is efficient and safety vertical transporting equipment
Applications:
SC serialization of products Building Hoist is a Rack and Pinion EL. Building Hoist widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.
Specifications
Standard technical datas of double cage :
|
Parameter |
SC100/100 |
SC160/160 |
SC200/200 |
SC270/270 |
SC320/320 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5 |
2*3*22 |
|
Cage inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Cage weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4 |
SAJ50-2.0 |
|
Hanger rated lifting capacity |
250 |
250 |
250 |
250 |
250 |
|
Rack module |
8 |
8 |
8 |
8 |
8 |
SC series building hoists:
1). Cage load capacity: 1000kg~3200kg;
2). Lifting speed:30m/min, 0~40m/min;0~60m/min;
3). Increased lifting height on request;
4). Mast section: Painted or hot dipped zinc
5). Cage:double cage
6). Recommended cage inner dimensions (L*W*H): 3*1.3*2.5m, 3*1
