HDLW11G OIL AND GAS TRANSMISSION PIPE ROLLING MACHINE
HDLW11G-20*12000
![\"317296867_517.jpg\"]()
Oil and gas transmission pipe rolling machine is our new patent
product, it includes the following technology:
1 we adopt the way of deformation-resistant to eliminate the deflection of top roller
2. Several group of oil cylinder for adding pressure on the two ends of top roller, and the piston rod is fixed, the up-down movement of oil cylinder drive top roller bear block to up and down, which use the space effectively and increase the utilization of material as well as decrease the weight of whole machine
3. The working piece (rolled shell) was taken out from inside of frame without turnover and reset of frame, which makes the operation more safe and reliable
The working piece (rolled shell) was sent out automatically driven by oil cylinder which is proper for flow process.
|
Model |
Max bending thickness(mm) |
Max plate width(mm) |
Top roller diameter(mm) |
Rolling diameter (mm) |
Main power (kw) |
|
HDLW11G-16*12000 |
3-16 |
12000 |
300 |
Φ317-Φ800 |
55 |
|
HDLW11G-16*12000 |
3-20 |
12000 |
350 |
Φ406-Φ1400 |
75 |
|
HDLW11G-16*12000 |
4-30 |
12000 |
500 |
Φ610-Φ1600 |
90 |
|
HDLW11G-16*12000 |
5-40 |
12000 |
560 |
Φ813-Φ1800 |
150 |
