Spiral Screen Pipe

Spiral Screen Pipe thumbnail-1
Spiral Screen Pipe thumbnail-2
Spiral Screen Pipe thumbnail-3
Spiral Screen Pipe thumbnail-4
Spiral Screen Pipe thumbnail-5
Spiral Screen Pipe photo-1
Spiral Screen Pipe photo-2
Spiral Screen Pipe photo-3
Spiral Screen Pipe photo-4
Spiral Screen Pipe photo-5
US$ 30 - 300 MOQ: 30 Sets
Key Specifications
Get Latest Price
Brand Name:
feiyatrade, xinlu wire mesh, xinlu wedge wire screen
Place of Origin:
China
Model Number:
1-20inch
Contact Supplier Request Quote Chat Now
Anping County Xinlu Wire Mesh Products Co.,Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin port, China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name feiyatrade, xinlu wire mesh, xinlu wedge wire screen
Place of Origin China
Model Number 1-20inch
Material Other, ss304, 304L, 316,316L.201,205,321, Q235,Q195, 2205,904L,etc
Type Other, filter pipe
Application Filter
Wire Gauge to order
Aperture 0.05-50mm
Hole Shape Square
Material: Stainless Steel Grade: 304
Slot Size: 0.5 Mm Diameter: 8 "
Length: 5800mm End Connection: Welded Rings
Package: Woden Box,Container

High Light: water well screen, water wire screen


304 Grade Continuous Slot Screen Vee Wire Screen 5800mm Length





Continuous Slot Screen Product Description:



Jonson Vee wire screen is welded by V wire and support rod.There is a fixed value slot between each v wire, and the continuous slot, designed to provide maximum open are to reduce entrance velocity, increase hydraulic efficiency and promote more effective development. The wrapped wire is V shape, and the support rod is O shape.



 Continuous Slot Screen Specification:



Material Stainless steel
Grade 304
O.D 219 mm
Size 8 "
Slot size 0.5 mm
Length 5.8 m
End connection Welded rings
Wire size 118 #
Support rod 140 #
Wire shape V shape



 Continuous Slot Screen Regular Specifications:



SIZE

(INCH)

O.D

(MM)

SLOT

(MM)

LENGTH

(M)

COLLAPSE

STRENGTH

(BAR)

TENSILE

WEIGHT

(TON)

WRAP WIRE(WIDTH*HEIGHT)

(MM)

RODS

(MM)
3-1/2 88.9 1.0 3 ＞22 10.2 2.3*3.5 3.8MM/22
4-1/2 114.3 1.0 3 ＞28 11.5 2.3*3.5 3.8MM/22
6-5/8 168.3 0.75 5.8 ＞40 12.8 2.3*3.5 3.8MM/32
6-5/8 168.3 1.0 5.8 ＞33 12.8 2.3*3.5 3.8MM/32
6-5/8 168.3 0.63 5.8 ＞83 45 3.2*6.0 6.0MM*32
8-5/8 219.1 1.0 5.8 ＞34 21.9 2.3*3.5 3.8MM/48
8-5/8 219.1 1.0 5.8 ＞50 38.2 3.0*5.0 4.0MM/48
8-5/8 219.1 1.0 5.8 ＞60 46 3.2*6.0 5.0MM/48
10-3/4 273.1 0.75 5.8 ＞50 32.9 2.3*3.5 4.9MM/55
10-3/4 273.1 1.0 5.8 ＞60 39.5 3.0*5.0 4.9MM/55
10-3/4 273.1 1.0 5.8 ＞100 48 3.2*6.0 5.0MM/55
12-3/4 323.9 1.0 5.8 ＞120 37.2 3.0*5.0 4.0MM/50
14 355.6 1.0 3 ＞80 37.8 3.0*5.0 4.0MM/59



Characteristic:



Not easy to jam

the special V shaped wire, make the hole of screen outside face is smaller than inside, so the hole is not easy to jam.

Slot even

The CNC machine tools strictly control the gap between the wire, so that the gap is even.

Strong corrosion resistance

Stainless steel 304 have the high corrosion resistance



OEM service:



Please tell us the specification of the wire screen you need, and we will help you to process the high quality products.



Custom range



Filter pipe material: mainly stainless steel, carbon steel galvanized, carbon steel spray or other customer requirements material.

Gap: 0.1mm-15mm, arbitrarily selected screen size to meet different construction requirements.

Diameter: 2 " 3 " 4 " 5 " 6 " 8 " 10 " 12 " 14 " 16 " 20 ". 29 mm - 1000 mm.

Length: 2.9 M, 5.85 M. Up to 6 M.

Connection form: groove connection/weld ring connection or thread connection.



Application:



Wre wrap screen pipe specific continuous-slot construction aims to optimize flow rates, minimize clogging and help develop the water-bearing geological formations faster. It is best applied in the following situations:
Geological formations comprised of small, fine particles
Water wells where gravel packs will be installed
Thin aquifers, where maximum open area is required
Large- and small-diameter deep wells
