Contact Person: Star Lee 86-0-13315867171
MSN: feiyatrade@hotmail.com
E-mail: starlee@feiyaguoji.com
Product name: v wire water well screens, wire wrapped screens pipe, Johnson Screen, spiral screen tube, welded wedge wire screen, reversed slot screen, continuous slot pre-pack, water filter, screen cylinders, stainless steel slot tube,reverse rolled screen, strainer pipe, continous slot wire wrap well screens, pipe base well screen, ribbed-type wire wrapped screen, stainlss steel or low carbon galvanized or mild steel wire screen, wire wrapped liner, woven wedge wire screen, slot wire screen tube, conical well screen, Suction strainers, strainer screens, wide slit screens, well point screens, PPS screen, oil screen tube, Well screen, water filter, filteration element
Specification (Profile wire):
Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70
Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30
Specification (support rods):
Width(mm): 2.30 3.00 3.30 3.70
Height(mm): 2.70 3.60 4.70 5.60 6.30
Round: From 2.50mm to 6.0mm Note: other wires and rods available upon request
Slot size: 0.10, 0.15, 0.20, 0.25, 0.30…. 6.00mm also achieved upon request.
Material: Low carton, low carton galvanized steel (LCG), stainless steel (304,316 etc.) Length: Lengths up to 6 meters.
Diameter : ranging from 25mm to1000mm.
End connection: Plain beveled ends for butt welding (welded ring)or threaded male &female coupling.(spiral)
Other sizes available on request.
Deep well construction specifications available on question. Water well screens are designed for depths of 100 m, 200 m, 350 m & 600 m.
