Milling Machine B600SC
- 300 Set / Sets per Month
- shenzhen
- T/T D/P D/A Credit Card
- Small CNC Milling Machine for School, Hobbist,Prototype,DIY
- YORNEW Desktop CNC Lathe Machine, education cnc, vocation cnc, hobby cnc, diy cnc
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
Product Details
Condition: | New | Brand Name: | XiaShi | Model Number: | B600SC |
Type: | Vertical | CNC or Not: | Normal | Power(W): | 7.5HP |
Dimension(L*W*H): | 2000*2230*2150mm | Weight: | 2900kg | Certification: | ISO9001,CE,3C |
Warranty: | 1Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Characteristics
1.Taiwan original milling head, sealed ballscrew. NSK P4 spindle bearing, spindle tolerance
0.002mm.
2.Bed type milling machine, strong stability, and heavy loaded.
3.Heavy loaded machine
4.Fit for plastic, mould processing and other strong cutting parts.
5.Unique spindle assembling technology, greatly improve the efficiency and accuracy of
cutting.
6.Spindle tolerance: 0.005mm
Features
1.Taiwan original milling head,NSK P4 spindle bearing;
2.Twice precisely scraping;
3.Head tilt angle ±45°/±90°;
4.OEM Manufacturer;
5.For electric parts, mould and hole, slot and frame processing;
6.Twice precisely scraping Fit for boring, milling, drilling and boring, tolerance is 0.005-0.012mm;
7.Spindle tolerance 0.002mm;
8.Parallel value between tables movement and table: X axis 0.015mm, Middle 0.01mm, Y
axis 0.01mm.
Technical parameter
Model | B600SC |
Table size | 1370*405mm |
Travel (Longitude) | 1000mm |
Travel (Cross ward) | 460mm |
Travel (Vertical) | 575mm |
Travel of spindle quill | 140mm |
Max.Distance from the spindle nose to table | 640mm |
Spindle (Rotation speed) | 60-3600RPM |
Spindle (Taper) | NT40 |
Spindle (Rated power) | 7.5HP |
Tilt Angle (Forward and Backward) | ±0° |
Tilt Angle (Left and Right) | ±90° |
Dimension | 2000*2230*2150mm |
Net weight | 2900kg |
After-sales services:
Warranty is a year, we would offer the parts( quality problem) free of charge during this period. Overseas service need to be charged extra.
Accessories:
1.Standard accessories:
Oil pump
Working light
Draw bar
Way cover
Operation manual
Tool and toolbox
2.Optional accessories:
NT40 Milling chuck
Clamping kits
6" vise
Coolant system
DRO
Mechanical Power feed
Elevating motor
Detailed pictures for your reference
If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
