Home > Products > WELDING MACHINE > BX6 AC.Arc Welding Machine--BX6-140, BX6-160
BX6 AC.Arc Welding Machine--BX6-140, BX6-160
Negotiable
1 (Min. Order)
You May Like
Product Details
| Condition | New | Model Number | BX6-160 | |
| Motor Type | AC Motor | Dimensions | 45*28*36cm, 49*34*49cm | |
| Voltage | 380/220 |
Product Description
Application:
The BX6 series as a general purpose manual arc welding power could be supplied for welding for work pieces in medium, small size for shorter time operating.
Structure Features:
The series of BX6's transformer is a leakage one. Different current can be obtained by adjusting the distribution of the turns of two parts of primary winding on the two iron core.
| Model | BX6-140 | BX6-160 |
| Powr Source Voltage (V) | 380/220 | 380/220 |
| Phase | 1 | 1 |
| Rated Input Capacity (KVA) | 7.6 | 9.0 |
| No-Load Voltage (V) | 52 | 55 |
| Rated Welding Current (A) | 140 | 160 |
| Current Adjusting Range (A) | 55-140 | 60-160 |
| Rated Duty Cycle (%) | 20 | 20 |
| Insulation Class | F | F |
| Dia. of Application Electrode (MM) | 1.6-3.2 | 2.5-4.0 |
| Dimensions (CM) | 45cm*28cm*36cm | 49cm*34cm*49cm |
| M³ of Each (M³) | 0.0454m³ | 0.0817m³ |
| Weight (KG) | 26 Kilogram (KG) | 35 Kilogram (KG) |
