Description:
- It is normally used for night construction and other field operation in the sectors of municipal engineering, road, bridge, port, mining and construction etc.
- Meanwhile, it also used on the occasion of night rush repairs and disaster relief site.
- Excellent performance, start easily.
The caution for the use:
- Reopen the spotlight after turning off the spotlight 20 minute later, don't plug it to until bulb is cooled down.
- Only start and stop the generator after turning off the spotlight.
- Don't use the generator in the rain. Otherwise, there is an electric shock. If necessary, you should check and service your generator after you cut-off electric circuit.
- Reduce the spotlight height when the wind speed is over 10m per second.
- Avoid putting the generator on the slope (above 5m). Otherwise, the generator will be tipped or sides, causing an accident.
- Keep the generator stable after stop. In addiction, fix the generator if necessary.
| Model | Tower Light | |
| Each lamp power | 400watt | |
| Weight (Kg) | ± 118kg | |
| Maximum height (m) | 5.0m | |
| Minimum heigh t(m) | 1.9m | |
| Lifted (L*W*H)(mm) | 1497mm*965mm*4267mm | |
| Standard (L*W*H)(mm) | 1497mm*965mm*2337mm | |
| Generator Model | 5GF-LDE | |
| ALTERNATOR | Alternator type | Synchronous alternator |
| Frequency / Voltage | 50 Hz / 240V | |
| Rated AC output | 4.4kva | |
| Max. AC output | 4.8kva | |
| Rated current | - | |
| DC output | 12V x 8.3A | |
| Power factor | 1 | |
| Excitation system | Self-excitation | |
| ENGINE | Model | BM186(FGE) |
| Type | Single-cylinder, Vertical, 4-stroke, Air-cooled, Direct-injection diesel. | |
| Displacement | 406 cc | |
| Bore x stroke | 86mm*70mm | |
| Speed | 3000rpm | |
| Continuous output | 7.7 hp | |
| Max. output | 8.8 hp | |
| Starting system | Recoil / Electric starter | |
| Cooling system | Forced air | |
| Governor system | Centrifugal weight system | |
| Fuel | Diesel | |
| Fuel tank capacity (Litre) | 16.5 L (Litre) | |
| Lub oil capacity | - | |
| Continuous working time | 8.5 hours | |
| Noise level (at 4mts) | 88 dB(A) | |
| UNIT | Frame - Type / Material | Monoblock. 2 support / Steel |
| Dimension(mm) | 880mm*565mm*795mm | |
| Dry weight (Kg) | 167 Kilogram (Kg) | |
