High Quality V-5000 Visible Spectrophotometer/ Wavelength Range 325-1000nm

High Quality V-5000 Visible Spectrophotometer/ Wavelength Range 325-1000nm thumbnail-1
High Quality V-5000 Visible Spectrophotometer/ Wavelength Range 325-1000nm photo-1
US$ 700 - 1,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Graigar
Model Number:
V-5000
Size:
420*280*180mm
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Graigar
Model Number V-5000
Size 420*280*180mm
Weight 8kg
Wavelength Range 325-1000nm

Specifications

High Quality V-5000 Visible Spectrophotometer/ Wavelength Range 325-1000nm

High Quality V-5000 Visible Spectrophotometer/ Wavelength Range 325-1000nm High Quality V-5000 Visible Spectrophotometer/ Wavelength Range 325-1000nm



V-5000 is a basic model with high cost-performance. High quality silicon photometric diode detector and 1200 lines/mm grating ensure the high accuracy and precision.
Features
Easy to use, Press one button for easy switching of Transmittance, Absorbance and Concentration modes.
Auto zero and blank
LED display is large enough to read from any distance, there’s no need to search or squint.
Large sample compartment, it can accommodate 5-100mm path length cuvettes with optional holders.
Pre-aligned design ensures the user to change lamp conveniently
Optional software based on windows® can expand the applications to Standard Curve & Kinetics.
Two-points-method to measure concentration of unknown samples.



Specifications



Model V-5000
Optical System Single Beam,Grating 1200lines/mm
Wavelength Range 325-1000nm
Spectral Bandwidth 4nm
Wavelength Accuracy ±1nm
Wavelength Repeatability 0.5nm
Photometric Accuracy ±0.5%T
Photometric Repeatability 0.3%T
Photometric Mode T, A, C, F
Stray Light ≤0.3%T
Stability ± 0.002A/h @ 500nm
Display 4 Bits LED
Detector Silicon Photodiode
Output USB Port & Parallel Port(Printer)
Light Source Tungsten Halogen Lamp
Power Requirements AC 85~250V
Dimension 420*280*180mm
Weight 8kg

 High Quality V-5000 Visible Spectrophotometer/ Wavelength Range 325-1000nm




Edited by ZACK
