High Grade UV-6100A UV/VIS Spectrophotometer(Bandwidth 1nm)

High Grade UV-6100A UV/VIS Spectrophotometer(Bandwidth 1nm) photo-1
US$ 7,000 - 7,500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Graigar
Model Number:
UV-6100A
Size:
625*430*206mm
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Graigar
Model Number UV-6100A
Size 625*430*206mm
Weight 28kg
Wavelength Range 190-1100nm
Measurement Range -0.3-3A,0-200%T,0-9999C

Specifications

High grade UV-6100A UV/VIS Spectrophotometer(Bandwidth 1nm)

High grade UV-6100A UV/VIS Spectrophotometer(Bandwidth 1nm)High grade UV-6100A UV/VIS Spectrophotometer(Bandwidth 1nm)



Features    The innovative optical layout and state of art mono-chromator with high grade blazed holographic grating ensure accuracy. Its integrated design assures long term stability and durability.     The precisely aligned detector and quality deuterium and halogen lamps enhance the precision across the UV/vis spectrum starting from 190nm and into the near-infrared 1100nm.     Online software upgrade capability via Internet(for stand-alone models)    Full A4 print-out of graphs and tables of results with popular inexpensive printers such as HP or Epson Deskjet.    Real-time clock for date and time stamping of results    Large LCD display (320*240 Dots Matrix)



Specifications







 Model UV-6100A
 Wavelength Range 190-1100nm
 Bandwidth 1nm
 Wavelength Accuracy ±0.3nm
 Wavelength Repeatability 0.2nm
 Photometric Accuracy ±0.3%T
 Photometric Repeatability 0.2%T
 Photometric Range -0.3-3A,0-200%T,0-9999C
 Stability ± 0.002A/h @ 500nm
 Baseline Flatness ± 0.001A/h
 Noise  ± 0.001A/h
 Stray Light ≤0.05%T @ 220nm,360nm
 Data Output Port USB
 Printer Port Parallel Port
 Display 320*240 Dots LCD
 Lamps D2  Lamp & W  Lamp
 Detector Silicon Photodiode
 Power Requirements AC   220V/50Hz or  110V/60Hz
 Dimension 625*430*206mm
 Weight 28kg


High grade UV-6100A UV/VIS Spectrophotometer(Bandwidth 1nm)
