Auto setting wavelength UV-5100B UV/VIS Spectrophotometer/Wavelength Range 190-1000nm

FOB Price

USD $1,900 - $2,500 / Piece

1 Piece(Min.Order)

Supply Ability 100 Piece / Pieces per Month
Port shenzhen
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	Graigar	Model Number:	UV-5100B	Size:	490370220mm
Weight:	15kg	Wavelength Range:	190-1000nm	Measurement Range:	-0.3-3A,0-200%T

Product Description

Specifications

Auto setting wavelength UV-5100B UV/VIS Spectrophotometer/Wavelength Range 190-1000nm

Features
Large LCD screen (128x64 Dots).
Can display and save 50 groups of data, 3 groups per screen.
Data can be restored after a sudden power cut.
Auto setting wavelength.
Tungsten lamp & deuterium lamp can be turned on/off individually to extend lifetime.
Automatical WL. calibration and dark current getting.
Optional software UV-Professional can expand the applications to Kinetics and Quantitatives.

Specifications

Model	UV-5100B
Optical System	Single beam, Grating 1200 lines/mm
Wavelength Range	190-1000nm
Bandwidth	4nm
Wavelength Accuracy	±1nm
Wavelength Repeatability	0.5nm
Wavelength Setting	Auto
Photometric Accuracy	±0.5%T
Photometric Repeatability	0.3%T
Photometric Range	-0.3-3A,0-200%T
Stray Light	≤0.3%T
Stability	± 0.002A/h @ 500nm
Display	128*64 Dots LCD
Detector	Silicon Photodiode
Standard Cell Holder	4-position 10mm cell changer
Light Source	Tungsten & Deuterium lamp
Output	USB Port & Parallel Port(Printer)
Power Requirements	AC 85~250V
Dimension	490370220mm
Weight	15kg

Edited by ZACK
