Auto Setting Wavelength UV-5100B UV/VIS Spectrophotometer/Wavelength Range 190-1000nm

Auto Setting Wavelength UV-5100B UV/VIS Spectrophotometer/Wavelength Range 190-1000nm photo-1
US$ 1,900 - 2,500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Graigar
Model Number:
UV-5100B
Size:
490*370*220mm
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Graigar
Model Number UV-5100B
Size 490*370*220mm
Weight 15kg
Wavelength Range 190-1000nm
Measurement Range -0.3-3A,0-200%T

Specifications

Auto setting wavelength UV-5100B UV/VIS Spectrophotometer/Wavelength Range 190-1000nm

Auto setting wavelength UV-5100B UV/VIS Spectrophotometer/Wavelength Range 190-1000nm

Auto setting wavelength UV-5100B UV/VIS Spectrophotometer/Wavelength Range 190-1000nm



Features
Large LCD screen (128x64 Dots).
Can display and save 50 groups of data, 3 groups per screen.
Data can be restored after a sudden power cut.
Auto setting wavelength.
Tungsten lamp & deuterium lamp can be turned on/off individually to extend lifetime.
Automatical WL. calibration and dark current getting.
Optional software UV-Professional can expand the applications to Kinetics and Quantitatives.

Specifications



Model UV-5100B
Optical System Single beam, Grating 1200 lines/mm
Wavelength Range 190-1000nm
Bandwidth 4nm
Wavelength Accuracy ±1nm
Wavelength Repeatability 0.5nm
Wavelength Setting Auto
Photometric Accuracy ±0.5%T
Photometric Repeatability 0.3%T
Photometric Range -0.3-3A,0-200%T
Stray Light ≤0.3%T
Stability ± 0.002A/h @ 500nm
Display 128*64 Dots LCD
Detector Silicon Photodiode
Standard Cell Holder 4-position 10mm cell changer
Light Source Tungsten & Deuterium lamp
Output USB Port & Parallel Port(Printer)
Power Requirements AC 85~250V
Dimension 490*370*220mm
Weight 15kg



Auto setting wavelength UV-5100B UV/VIS Spectrophotometer/Wavelength Range 190-1000nm

Edited by ZACKAuto setting wavelength UV-5100B UV/VIS Spectrophotometer/Wavelength Range 190-1000nm
