Home > Products > Optical Instruments > Large LCD screen UV-5500(PC) UV/VIS Spectrophotometer can display standard curve and the curve equation

Large LCD screen UV-5500(PC) UV/VIS Spectrophotometer can display standard curve and the curve equation

FOB Price

USD $4,100 - $4,500 / Piece

1 Piece(Min.Order)

Supply Ability 100 Piece / Pieces per Month
Port shenzhen
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Graigar	Model Number	UV-5500(PC)
Size	460360225mm	Weight	18kg
Wavelength Range	190-1100nm	Measurement Range	-0.3-3A,0-200%T,0-9999C

Product Description

Specifications

Large LCD screen UV-5500(PC) UV/VIS Spectrophotometer can display standard curve and the curve equation

Features Large LCD screen(128x64Dots).Can display total 200 groups of data,5 groups per screen. Can display standard curve and the curve equation. Can save 200 groups of curve equation. Convenient for check and reload. Data can be restored after a sudden power cut. Auto setting wavelength. Auto zero and blank. Tungsten lamp & deuterium lamp can be turned on/off individually to extend lifetime. The Metash application software UV-Professional provides complete control of the spectrophotometer from a computer through the Built-in USB port. The following functions can be easily achieved: Quantitative, Kinetics, Wavelength Scan, DNA/Protein Test and Multi-wavelength Test. The flange of the D2 lamp makes it become true Pre-aligned design makes it convenient to change lamps. Large sample compartment, It can accommodate 5-100mm path length cuvettes with optional holders. A variety of optional accessories are under your choice.

Specifications

Model	UV-5500(PC)
Optical System	Single beam, Grating 1200 lines/mm
Wavelength Range	190-1100nm
Bandwidth	2nm
Wavelength Accuracy	±0.5nm
Wavelength Repeatability	0.3nm
Wavelength Setting	Auto
Photometric Accuracy	±0.5%T
Photometric Repeatability	0.3%T
Photometric Range	-0.3-3A,0-200%T,0-9999C
Stability	± 0.002A/h @ 500nm
Stray Light	≤0.1%T
Data Output Port	USB
Printer Port	Parallel Port
Display	128*64 Dots LCD
Lamps	D2 Lamp & W Lamp
Detector	Silicon Photodiode
Power Requirements	AC 220V/50Hz or 110V/60Hz
Dimension	460360225mm
Weight	18kg

Edited by ZACK
