Large LCD Screen UV-5500(PC) UV/VIS Spectrophotometer Can Display Standard Curve and the Curve Equation

Large LCD Screen UV-5500(PC) UV/VIS Spectrophotometer Can Display Standard Curve and the Curve Equation photo-1
US$ 4,100 - 4,500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Graigar
Model Number:
UV-5500(PC)
Size:
460*360*225mm
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Graigar
Model Number UV-5500(PC)
Size 460*360*225mm
Weight 18kg
Wavelength Range 190-1100nm
Measurement Range -0.3-3A,0-200%T,0-9999C

Specifications

Large LCD screen UV-5500(PC) UV/VIS Spectrophotometer can display standard curve and the curve equation

Large LCD screen UV-5500(PC) UV/VIS Spectrophotometer can display standard curve and the curve equation Large LCD screen UV-5500(PC) UV/VIS Spectrophotometer can display standard curve and the curve equation



 Features    Large LCD screen(128x64Dots).Can display total 200 groups of data,5 groups per screen. Can display standard curve and the curve equation.    Can save 200 groups of curve equation. Convenient for check and reload.    Data can be restored after a sudden power cut.    Auto setting wavelength. Auto zero and blank.    Tungsten lamp & deuterium lamp can be turned on/off individually to extend lifetime.    The Metash application software UV-Professional provides complete control of the spectrophotometer from a computer through the Built-in USB port. The following functions can be easily achieved: Quantitative, Kinetics, Wavelength Scan, DNA/Protein Test and Multi-wavelength Test.    The flange of the D2 lamp makes it become true Pre-aligned design makes it convenient to change lamps.    Large sample compartment, It can accommodate 5-100mm path length cuvettes with  optional holders. A variety of optional accessories are under your choice.



 Specifications







 ModelUV-5500(PC)
 Optical System  Single beam, Grating 1200 lines/mm
 Wavelength Range190-1100nm
 Bandwidth2nm
 Wavelength Accuracy±0.5nm
 Wavelength Repeatability0.3nm
 Wavelength SettingAuto
 Photometric Accuracy±0.5%T
 Photometric Repeatability0.3%T
 Photometric Range-0.3-3A,0-200%T,0-9999C
 Stability± 0.002A/h @ 500nm
 Stray Light≤0.1%T
 Data Output PortUSB
 Printer PortParallel Port
 Display128*64 Dots LCD
 LampsD2  Lamp  &  W  Lamp
 DetectorSilicon Photodiode
 Power RequirementsAC   220V/50Hz or  110V/60Hz
 Dimension460*360*225mm
 Weight18kg

Large LCD screen UV-5500(PC) UV/VIS Spectrophotometer can display standard curve and the curve equation
