Excellent Optical System And Electric Circuit Design UV-5800(PC) UV/VIS Spectrophotometer DNA/Protein Test

FOB Price

US$ 4,900 - 5,100 / Piece

1 Piece(Min. Order)

Port shenzhen
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Graigar	Model Number	UV-5800(PC)
Size	460360225mm	Weight	18kg
Wavelength Range	190-1100nm	Measurement Range	-0.3-3A,0-200%T,0-9999C

Product Description

Specifications

Excellent optical system and electric circuit design UV-5800(PC) UV/VIS Spectrophotometer DNA/Protein Test

Low Stray Light The stray light of UV-5800(PC) is below 0.05%T.The monochomator is totally sealed and the optical surfaces are protected with a silicon dioxide membrane.The excellent optical system and electric circuit design ensures the very low stray light. Large LCD display Models UV-5800(PC) adopt 128*64 Dots LCD as its display system. Thus makes the results easy to read. And the Standard Curve can be displayed on it clearly,Also,it can display 5 groups of data per screen. Large Data memory space It can store 200 groups of data and 200 standard curves at the same time.Press arrow key to scroll,easy to reload. Can upgrade to scanning modle The instrument can be controlled by Metash’s scanning software UV-Professional developed based on Windows® through the USB port.The software expands the function to Quantitative,Kinetics,Multiwavelength and Wavelength Scanning.

Specifications

Model	UV-5800(PC)
Wavelength Range	190-1100nm
Bandwidth	2nm
Wavelength Accuracy	±0.5nm
Wavelength Repeatability	0.2nm
Wavelength Setting	Auto
Photometric Accuracy	±0.3%T
Photometric Repeatability	0.2%T
Photometric Range	-0.3-3A,0-200%T,0-9999C
Stability	± 0.002A/h @ 500nm
Baseline Flatness	± 0.0015A/h
Stray Light	≤0.05%T
Data Output Port	USB
Printer Port	Parallel Port
Display	128*64 Dots LCD
Lamps	D2 Lamp & W Lamp
Detector	Silicon Photodiode
Power Requirements	AC 220V/50Hz or 110V/60Hz
Dimension	460360225mm
Weight	18kg
