2 Color Paper Flexo Printing Machine (CE)
1.The main features
1. Take it easy, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity, running small fluctuations
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. The use of special diagonal-tooth gear, print size is accurate,
5. There are two sets of heating devices, including central heating and constant temperature control system for packet control
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced
8 With a cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. The Print produce are clear and good arrangement quality
10. Bearing: NSK, Japan brand, Germany ASNU aluminum alloy roll
2.Main Technical Parameter
Max. Material width |
650mm |
850mm |
1050mm |
1250mm |
1450mm |
1650mm |
Max. Printing width |
560mm |
760mm |
960mm |
1160mm |
1360mm |
1560mm |
Printing material |
Single adhesive paper,Double adhesive paper,Copper plate paper, Kraft paper :50-350g/m2 Single filter membrance paper,Double filter membrance paper : 80-350g/m2 |
|||||
Printing color |
2 special color |
|||||
Printing length |
7.5"-40"_90mm-1016mm |
|||||
Printing plate lifting system |
Hydraulic press control |
|||||
Mechanical speed |
90m/min |
|||||
Printing speed |
10-70m/min |
|||||
Anilox roller |
Metal: 100-300LPI Or Ceramic anilx roller(200-1000LPI), single doctor blade |
|||||
Register precision |
Longitude:±0.25mm Transverse: ±0.25mm |
|||||
Rewinder/Unwinder DIA |
ø 800mm/ ø 1000mm/ ø 1200mm/ ø 1500mm |
|||||
Master power |
14KW |
18KW |
20KW |
22KW |
24KW |
26KW |
Weight |
3500Kg |
3800 Kg |
4000 Kg |
4000 Kg |
4200Kg |
4300 Kg |
Dimension |
5.2m |
5.2m |
5.3m |
5.3m |
5.4m |
5.4m |
1 Year Guarantee !
100% Good Quality !
24 Hours online Service!
