CJ886/ 600 6 Color Roll paper / Kraft paper Flexographic Printing Machine
1. The main features:
1. Take it easy, accurate color, long life.
2. Use motors, variable frequency speed control, saving electricity, small running fluctuations.
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink.
4. Use special synchronous belt drive, accurate printing size.
5. Two sets of heating devices, including central heating and constant temperature control system for group control.
6. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium.
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced.
8 With cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. Print produce are clear and good arrangement quality.
10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll
2. Main parameter:
Machine running |
Use Synchronous belt drive instead of Helical Gear drive Advantage: 1.Lower machine runnning noise 2.Highwe printing precison, hetter printing quality, 3.less gear line on printing sample then gear drive machine. 4.Well machine working smooth |
|||||
Model |
CJ886-600 |
CJ886-800 |
CJ886-1000 |
CJ886-1200 |
CJ886-1400 |
CJ886-1600 |
Max. Material width |
650mm |
850mm |
1050mm |
1250mm |
1450mm |
1650mm |
Max. Printing width |
560mm |
760mm |
960mm |
1160mm |
1360mm |
1560mm |
Printing Material |
Single adhesive paper,Double adhesive paper,Copper plate paper,Kraft paper :50-350g/m2 Single filter membrance paper,Double filter membrance paper : 80-350g/m2 |
|||||
Printing color |
PC:6+0 |
|||||
Printing length |
7.5"-40"/7.5"-50"/ |
|||||
Printing plate lifting system |
Hydraulic press control |
|||||
Mechanical speed |
90m/min |
|||||
Printing speed |
10-70m/min |
|||||
3. Detailed parameter:
3.1) unwind unit:
Max. unwind diameter |
Φ1200mm |
Unwind Way |
Auto loader for unwind, with 10KG powder magnetic and auto tension control 1pcs |
Tension precision |
±0.3kg |
EPC System for unwind |
1pcs |
Unwind material holder |
By air shaft , 1 pcs |
Unwind web cylinder |
Φ76mm (inner diameter) |
3.2) Printing Unit:
Principle of Work |
Belt Drive |
Suitable Printing Ink |
Water-based ink or Oil-based ink |
Material of Plate |
Resin or Rubber |
Constitution of Printing |
Chrome plated roller, Rubber roller, Anilox roller, Plate cylinder |
Anilox roller |
3 standards of machine: 1. Standard machine: metal anilxo roll 2. High quality: ceramic anilox roller ,doctor blade |
Printing Pressure |
Mechanical adjust |
Color register type |
By Manual |
Printing plate lifting system |
Automatic Hydraulic cylinder control roll up and down |
3.3) Heating and Drying Unit:
Dryer |
Electrical heat drying |
Blower |
4kw x 1pcs |
Double Blower way circle |
Centralized heat, exhaust gas pumpback |
Power of Heating |
24 kw |
3.4) Rewind Unit:
Max. rewind diameter |
Φ1200mm |
Rewind Way |
Surface rewind; |
Tension control system |
Tension float roller 1pcs for rewind unit |
Rewind material holder |
By air shaft , 1pcs |
Rewind motor |
1.5Kw, Taiwan motor |
Rewind web cylinder |
Φ76mm (inner diameter) |
Optional parts which extra cost buy:
NO. |
Goods of Descriptions |
1 |
Printing cylinder which use on flexographic printing machine |
2 |
Corona treatment |
3 |
Monitor system (also called image inspect device): screen+camera+controller |
4 |
Pate mounting machine(easier to mount plate) |
5 |
Plate making machine |
6 |
Anilox roller cleaning machine ( especially client buy machine for paper printing) |
7 |
Ink viscosity measurement ( 1 color need 1pcs) |
1 Year Guarantee !
100% Good Quality !
24 Hours online Service!
