117 Portable filling station to fill cars directly, 200bar

Specifications

1. CNG refueling station trailer;
2.4130X, 20Mpa, 8 tubes, 4540NM3;
3.Fill cars directly, part of gas daughter station
4.BV

CNG refueling station trailer(200bar) manufactured by Zhongyou Tongyong Luxi Natural Gas Equipment Co.,Ltd which connected with a gas release container with two dispensers(four nozzle) on it, sell gas to vehicle, it’s mobile and could fill around 2000NM3 per hour.



Equipments and work flow of daughter station:







CNG daughter refueling station is composed by three parts: hydraulic booster skid, CNG daughter station trailer, and CNG dispensers etc. CNG daughter station trailers can be manufactured by us.

About CNG daughter station trailer:

A special kind of oil will be filled to the cylinders mounted on the CNG trailer through the high-pressure pump, pushing the CNG in the cylinder flowing out and filled into vehicles through dispensers. It’s cost effective and energy saving.

Air displacement(NM3/H): 1000, 2000;

Discharge rate: no less than 95%;

Power(KW):30, 60.



Specification:



8- CNG Daughter station Skid cascade container   20MPa
Item		Data	Item		Data
Total cascade	Unit Weight	23200Kg	Cylinder Quantity	Working Pressure	20MPa
	Full-loaded Weight	2933Kg(20°C)		Working Temp	-40~60°C
	Total Weight	26133Kg		Cylinder Material	4130X
	Working Pressure	20MPa		Water Capacity	2.25m3
	Working Temp	-40~60°C		Cylinder Qty	8
	Filling Medium	CNG		Total Capacity	18 m3
	Testing Pressure	20		Testing Pressure	33.4MPa
	Filling Capacity	4540Nm3		(ODxWTKxL)	φ559x16.8x10950mm
	Dimension	12192x2438x1435mm
Bursting discs	Burst Pressure	33.4 MPa	Release-hole Diameter		≥φ20
Total Container	Unit Weight	7600kgs	Dimension(LxWxH)		12960x2495x3000mm
	Total Weight(full-loaded)	38080kgs	Wheelbase		7120+1350+1350mm
	Model of Semi-trailers	THT9380ZJZ	Tire		11.00R20



Corporation:



Zhongyou Tongyong Luxi Natural Gas Equipment Co.,Ltd. is a CNG container and LNG trailer manufacturer since 2008,a joint venture between Sinogas General Group (public listed company) & Luxi Chemical Co., Ltd (public listed company). Annually production of of Jumbo cylinders is more than 15,000 pcs. All the CNG containers will be inspected by BV before delivery and are insured by PICC, Amount insured is around 10 million USD.
