Yd-22II Hydraulic Rail Tamping Machine
USD $4500 - $4745
/ Set
1 Set(Min.Order)
- 500 Set / Sets per Month
- shenzhen
- T/T
- 15 days
You May Like
- Hydraulic Railway Track Lifting and Lining Machine
- Hydraulic Railway Track Jack for Rail Lifting and Lining
- Yqbj-300*200II Hydraulic Rail Lifting and Lining Machine
- Electric Rail Drilling Machine Railroad Drill Machine Light Weight Rail Drill Machine
- Magnetic Rail Curve Tool
- Laser Alignment Device railway parts accessories railway maintenance equipment
Product Details
Brand Name: | linkage | Place of Origin: | China | Model Number: | YD-22II |
Dimensions (L x W x H) (mm): | 134*76*171CM |
Product Description
Hydraulic tamping machine is a professional machine used for railway line works maintenance, which can operate at train interval without blocking the section. Equipped with internal combustion engine or electric motor for power, hydraulic transmission, each machine one person operation, manual implementation. It is provided with a lower road frame, and does not violate the "limit" after the lower road.
Model | YD-22II |
Type | Rail Tamping Machine |
Engine | asoline engine GX390, Power 9.5kW, R.P.M: 3600 r / min |
Dimensions (L x W x H) (mm) | 1350 × 760 × 1710mm |
Hydraulic system working pressure | 5 ~ 6MPa |
Vibrating frequency | 66.7Hz |
Vibrating force | 22kN |
Max insert force | 18.4kN |
Insert depth | 110mm ± 10mm ( underneath the sleeper) |
Working efficiency | ≥ 260 pieces / (group.hour) |
Weight | 425kg |
