Machine features:
Punching machine is suitable for various kinds of steel, iron, copper, aluminum, steel, angle steel,
channel steel, forming, punching, bending, cutting operation; hydraulic transmission, has the
advantages of light weight, small volume, low noise, easy operation and other advantages, is the
modern machinery manufacturing industry such as: ideal equipment for metallurgy, bridges,
communications, power, building, steel structure, mechanical processing industry.
This machine is matched with other mold, can do the special shape of sheet metal bending 90°,
V-notch shear
This machine adopts hydraulic transmission, the reasonable structure, light weight, low noise,
convenient and reliable
Technical parameters:
| Model | 25Y-115T |
| Punching Pressure(T) | 115 |
| Plate strength(N/mm2) | ≤450 |
| Slider trip(mm) | 80 |
| Trips frequency(times/min) | 10-18 |
| Punching Thickness(mm) | 25 |
| Max.punching diameter(mm) | 35 |
| Throat depth(mm) | 480 |
| Main Motor Power(KW) | 7.5 |
| Overall diamensions(L×W×H)(mm) | 1800×960×2000 |
Model you can choose:
Pictures:
