CLC Cellular Lightweight Concrete Block Machine
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Henan, China | |
| Brand Name | SYM | Model Number | SYT-20 | |
| Motor Power | 25.85kw totally | Mixing Power | 11kw | |
| Charging Capacity | 1.5CBM/time | Reclaiming capacity | 1.8CBM/time | |
| Speed of Mixing Drum | 32r/min | Water Supply Mode | Auto | |
| Working Cycle Period | 6-10min | Discharge Way | Auto | |
| Outline Dimension | 2600*2250*2800mm | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Lightweight Foam Concrete Mixing Machine (SYT20)
Introduction:
light concrete mixing machine is specially designed for Cellular light weight concrete, it force raw materials to mix fast and homogenously by the strong circular motion and impact.
An ideal Mixer for Cellular light weight concrete Due to its high automation, compact structure, reliable performance, easy operation, convenient maintenance etc.
Main Technology Data:
Model | AJT10 | SYT20 | JSP40 |
Output | 400L | 1500L | 3500L |
Input | 443L | 1800L | 4000L |
Capacity | 3-5m3/h | 5-10m3/h | 12~21m3/h |
Main shaft Speed | 32m/min | 32m/min | 30r/min |
Lifting speed | - | 22m/min | - |
Dimension | 1850*600*1050mm | 2600*2250*2800mm | 4000*3200*4200mm |
Total weight | 1200kg | 3200kg | 4200Kg |
Travelling speed | No more than 15KM/H. | No more than 15KM/H. | - |
Motor powder | 3kw+3kw+3kw+0.75kw | 11KW+5.5KW+1.1KW+0.55KW +5.5kw+3kw | 18.5kw+7.5kw+3kw+3kw |
Products:
Packing & Shipping:
Mass block mould and Demoulder
What's the Big Block Mould looks like?
| CLC block moulds Block mould combined Mould Frame and Mould Bottom Trolley together. |
| Steel thickness: 4mm |
| Mould Bottom height: 240mm |
| Overall Dimension: 1300*1300*840mm |
Two kinds of block moulds for your choice: one kind made by steels, the other kind made by wooden plastic boards.
What's the demoulder looks like?
| Demould machine, worked together with the big block moulds, is used to move the mould frames, has many advantges such as easy operation, stable performance, can keep good foam concrete block shape. |
