Home > Products > Foam Concrete Pump > Foam Concrete Hydraulic Pump

Foam Concrete Hydraulic Pump

FOB Price

US$ 18,000 - 22,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Power Type	Electric
Place of Origin	Henan, China	Brand Name	SYM
Model Number	SYT-30	Power(W)	30KW
Weight	1900kg	Dimension(LWH)	31009201300mm
Warranty	12months	After-sales Service Provided	Engineers available to service machinery overseas

Hydraulic foam concrete pump,
Vertical delivery height no less than 100m, Horizontal delivery length no less than 300m

SYT-30 Hydraulic Foam Concrete Pump

Features:

1. Adopting wear resistant metal, sturdy and durable.

2. Full automatic control system, to adjust the foam concrete density easily.

3. Adopting the famous brand good quality components, reliable quality.

4. Adopting hydraulic two cylinders single conveying way to send the foam concrete to the construction plant on-site, stable flow, small fluctuation.

5. Equipped with travelling wheel, easy moving and position.

6. Equip the remote control handle with the electric cabinet, convenient operation.

Technical Data:

ITEM	DATA
Max. theoretical grouting flow	30 m³/h
Max. theoretical conveying pressure	8 Mpa
Max. theoretical horizontal transporting range	600 m
Max. theoretical vertical transporting height	200 m
Max. particle size of aggregates	8 mm
Pump head quantity	2 Pcs
Oil cylinder (material cylinder) quantity	2 Pcs
Oil cylinder inside diameter*stroke	Φ80*1000 mm
Material cylinder inside diameter*stroke	Φ140*1000 mm
Max. pressure of hydraulic system	24 Mpa
Oil pressure box volume	200L
Motor power	30 KW
Dimension (LWH)	31009201300 mm
Weight (whole machine)	1900 kg

Pump in construction site
