Home > Products > Foam Concrete Mixer Machine > SYT-20 CLC cellular lightweight concrete making machine, CLC foam concrete machine
SYT-20 CLC cellular lightweight concrete making machine, CLC foam concrete machine
- 100 Set / Sets per Month
- Qingdao Shanghai Tianjin or other ports
- T/T
- China pe200x300 smallest jaw crusher
- Popular compound pendulum jaw crusher price
- 2016 china products stone coated steel roofing tile ,shingle steel roof tile
- 2016 china products lightweight roof tile,blue glazed roof tile
- colored metal roofing prices,sand coated metal roofing tiles
- roofing tiles coated with stones,roofing tiles for houses
Product Details
Condition: | New | Type: | Other, CLC Brick Making Machine | Brick Raw Material: | Other, Cement, Flyash, Sand, Cinder etc one or two more |
Processing: | Brick Production Line | Method: | Other, Non Autoclave Aerated Concrete | Automatic: | Other, Semi-auto |
Capacity: | 5-10m3/h | Place of Origin: | Henan, China | Brand Name: | SYM |
Model Number: | SYT-20 | Voltage: | 380V/50HZ or made as clients requirements | Power: | 11kw+5.5kw+5.5kw+2.2kw+1.1kw+0.37kw |
Dimension(L*W*H): | 2600*2250*2800mm | Warranty: | 1year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
SYT-20 Light Concrete Mixing Machine
foam generator, mixer hopper, feeder hopper, water pump and control panel are included in the foam concrete machine.
Features:
1. The foam blending fast, blowing foam uniformly.
2. Without suspended matter, without the declining, it’s good for steady pouring.
3. Little loss ratio of foam maintain the foam proportion in the foam concrete to make the products with stability density.
4. No dead angle design, mixing the material toughly, storage in its bottom is less than 10mm, no material left on the four walls internal the mixing drum.
5. It could mixing variable materials, such as cement, fly ash, sand pulp, sand stone, pearlite, and slag etc.
6. Variable speed mixing and internal structure alteration make its installation easy and mixing frequency high, it saves energy.
MACHINE NAME& TECHNICAL DATA | |
SYT-20 Foam concrete mixing machine | |
Output volume | 1500L |
Material input volume | 1800~2000L |
Capacity | 6-10m3/h |
Main shaft revolution | 32r/min |
Hopper lifting speed | 22m/min |
Overall dimension | 2600*2250*2800mm |
Total weight | 2600kg |
Mixing motor | 11kw |
Winding motor | 5.5kw |
Water pump motor | 1.1kw |
Vibrating motor | 0.37kw |
Foaming system | 2.2kw |
Air compressor | 5.5kw |
Max. travelling speed | ≤15km/h |
IHP-series Foam Concrete Pump
Such concrete pump also called peristaltic pump could be used for pumping the mortar, foam concrete machine etc.
GYC-60B Foam concrete block cutting machine
GYC-60B New Wire Cutting Machine is improved on the basis of the GYC-60A wire cutting machine, It is specially used to cut various foam concrete blocks. Easy operation, high efficiency.
New wire cutting machine main performances:
1. Six shafts equipped with bearings, reduce the friction, and increase the rope wire lifetime.
2. Both horizontal and vertical cutting are cutting both way, keep the blocks more stable, and get good shape blocks.
3. Lifting speed could be also adjusted under the chain drive and lifting motor, more stable.
4. Two cutting motors equipped on the cutting frame, save space, and make the structure more impact.
5. Steel doors instead of the guard grids, more easy for daily maintenance.
6. Add cover on the top of the cutting machine, make the cutter elegant appearance.
7. Improved the control panel too, it is available for 380V/50HZ~460V/50HZ.
Technical Data:
Item | Data |
Overall dimension (L*W*H) | 2160*2220*2280mm |
Cutting platform size (L*W*H) | 1300*1300*600mm |
Net cutting size (L*W*H) | 1200*1200*600mm |
Motor | 1.5kw*1set, 0~560r/min adjusted |
550w*2sets, 0~560r/min adjusted | |
Effective hoisting height | 800mm |
Total weight | 1200kg |
Cutting cycle | 3-6mins |
