Xcmg Slm3500 3.5cbm Selfing Loading Mixer Machine Only 19999usd per Unit

Name: Xcmg Slm3500 3.5cbm Selfing Loading Mixer Machine Only 19999usd per Unit
Brand: sdlt
SKU: 172969488
Availability: InStock

US$ 19999 ≥1 Set

Key Specifications

Brand Name:

sdlt

Place of Origin:

China

Model Number:

slm3500

Sdlt Shandong Heavy Industry Co.,ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO,CHINA

Delivery Detail:

15 days

Brand Name sdlt

Place of Origin China

Model Number slm3500

After-sales Service Provided Engineers available to service machinery overseas

Condition New

Outline Dimension 7500x2500x3250

Discharge Way auto

Working Cycle Period auto

Water Supply Mode auto

Speed of Mixing Drum 22

Reclaiming capacity 3.5cbm

Charging Capacity 5cbm

Mixing Power 60kw

Motor Power 76kw

Attn:
Tel/E-mail:
MODEL	Description				EXW RMB	Pictures
MODEL	Overall performance		Unit	Value	1 unit/40'HC	Pictures
H30		Engine Type		Yuchai 4105 Turbocharging	148,000.00
		Engine power(KW)	KW	85
		Drum Capacity(m³)	m³	5.5
		Valid output(m³)	m³	3.5
		Overall dimension LengthWidthHeight(mm)	mm	615027003350
		Axle base	mm	2450
		Front wheel base	mm	1680
		Rear wheel base	mm	1680
		Dumping height	mm	1400
		Minimum ground clearance(mm)	mm	290
		Total weight(KGS)	KGS	8000
		Fuel consumption (Theoretical)L/H	L/H	8.0-10.0
		Maximum drive speed	KM/H	25
		Tank rotation speed	Turn/minute	18
		Tank rotation angle	°	270
		Drive Bridge		big hub reductor
		Gear box		280
		Tire Dimensions (Front)		12R22.5(Double Tire)16/70-20(Single Tire)
		Tire Dimensions (Rear)		12R22.5or16/70-20
		Braking distance	mm	1000
		Engine oil capacity	L	13
		Hydraulic oil capacity	L	120
		Hydraulic oil type	L	No. 46 efficient wearable
		Fuel tank	L	120
		Water tank	L	750
		Small pump displacement	L/MINUTE	150
		Big pump displacement	L/MINUTE	150
		Radius of turning circle		6
		Bucket capacity	m³	0.6
		Transmission oil type/capacity	L	No. 8 transmission oil/50
		Axle gear oil type/capacity	L	No. 18 double curve bight/3.5
		Hub reduction gear oil type/capacity		No. 18 double curve bight/1.8
		Double tire pressure	Bar	10
		Single tire pressure	Bar	6
		Tank pressure	Bar	4.0-8.0
This price includes high-pressure car wash pumps;
Air conditioner: usd450.00; Cement hopper: usd200.00
3000
1500
1500
5500
1000
