Specifications
1. table guideways with high stability2. automatic feed on X,Y axies
3.headstock swivels 45
The X5032 is an light ,economical and applied vertical knee-type milling machine.
The machine is used for cutting metals, it's an universal milling machine. Cylinder mill, round piece mill, shape mill and end mill can be installed on the conical hole of main pivot of the machine, which is suitable for processing plane surface, oblique plane, groove, hole, gear of all kinds of small, medium parts. User can select universal dividing head (a special auxiliary) to process groove of thread. The machine is an ideal processing equipment for machine manufacturing, mold, instrument, automobile, motorcyole and other trades.
SPECIFICATION | UNIT | X5032 |
Spindle taper | mm | 7:24 ISO40 |
Distance between spindle nose and worktable | mm | 50-600 |
Distance between center vent of spindle and guideway | mm | 350 |
Range of spindle speed | r.p.m | 35-1350(12step) |
Flow of cooling pump | L/min | 25 |
Table size | mm | 1500 x 320 |
Table travel | mm | 850 x 350 x 500 |
Motor power | kw | 3/1.1/0.75/0.09 |
N.W | kg | 2200 |
