CNC Vertical Knee-Type Milling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
HELI
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Universal Milling Machine XQ6226WNegotiableMOQ: 4 Sets -
X6325W Vertical and Horizontal Turret Milling MachineNegotiableMOQ: 4 Sets
-
XQ6226A Universal Milling MachineNegotiableMOQ: 4 Sets
-
Universal Milling Machine XQ1450WAUS$ 10600 - 11500MOQ: 1 Set
-
Universal Milling Machine XL6236NegotiableMOQ: 4 Sets
Condition
New
Place of Origin
Shandong, China
Brand Name
HELI
Model Number
XK5032
Type
Vertical
CNC or Not
CNC
Specifications
1.Highly stability| XK5032 CNC Knee type milling machine No. of control axes 3 (The forth axis is optional) 3(The forth axis is optional) Simultaneous controlled axes 3 |
SPECIFICATIONS | UNIT | XK5032 |
Table size | mm | 1600 x 320 |
T-slots(NXWXD) |
| 3/18/70 |
Longitudinal travel | mm | 900 |
Cross travel | mm | 360 |
Vertical travel | mm | 350 |
Table longitudinal feed(auto) |
| stepless |
Table cross feed(auto) |
| stepless |
Table vertical feed(auto) |
| stepless |
Distance between spindle nose and table surface | mm | 45-415 |
Spindle taper |
| 7:24 ISO 50 |
Number of spindle speed |
| 18 |
Spindle speed range | r.p.m | 30-1500 |
Max.swivel angle of spindle | ° | ±45° |
Spindle travel | mm | 70 |
Main motor power | kw | 7.5 |
X,Y,Z to feed AC servo motor torque | Nm | 10/10/15 |
Overall dimensions | mm | 2294 x 2050 x 1904 |
N.W | kg | 3200 |
