Vertical Knee Type Milling Machine X5036B

Name: Vertical Knee Type Milling Machine X5036B
Brand: HeLi
SKU: 103162111
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

HeLi

Tengzhou Runfa Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name HeLi

Model Number X5036B

Type Vertical

CNC or Not Normal

Specifications

The machine is used for cutting metals, it's an universal milling machine.

Cylinder mill, round piece mill, shape mill and end mill can be installed on

the conical hole of main pivot of the machine, which is suitable for processing

plane surface, oblique plane, groove, hole, gear of all kinds of small, medium parts.

User can select universal dividing head (a special auxiliary) to process groove of thread.

The machine is an ideal processing equipment for machine manufacturing, mold, instrument,

automobile, motorcyole and other trades.

SPECIFICATION	UNIT	X5036B
Spindle taper		7:24ISO 50
Distance between horizontal spindle center and plane of suspension girder	mm
Distance between spindle nose and worktable	mm	60-420
Range of spindle speed	r.p.m	60-1700
Table size	mm	1370 x 360
Table travel(horizontal/cross/vertical)	mm	1000/ 320/360
Speed of longitudinal,cross travel	mm/min	(8steps)12-370(rapid feed 550)
Speed of worktable vertical feed	mm/min	590
T-slot No./Width/Distance of rotary table	mm	3/18/80
Suspension girder travel	mm	---
Main motor power	kw	4
Motor power for worktable feed	w	750
Motor power for up&down table	w	1100
Motor of coolant pumps	w	90
Flow of coolant pumps	L/min	25
Overall Dimension	mm	1700 x 1680 x 1880
N.W/G.W	kg	2200/2500
