Help CenterM80‑5000000M1‑06‑335‑00‑000 HARWIN Connector, 6‑Position Male Plug, 4.0mm Pitch, Jackscrew Lock, 12AWG, Datamate‑Power Cable‑mount Kit
Product Spotlights
2. Gold‑plated beryllium‑copper contacts, low contact resistance, anti‑oxidation, 500 mating cycles
3. Glass‑filled PPS housing, UL94‑V‑0 flame‑retardant,‑55℃~+125℃ wide operating temperature
4. Matching female receptacle available for one‑stop‑supply
Related Products
-
M80‑4T10405F1‑04‑321‑00‑000 HARWIN Datamate Mix‑Tek, 4‑Signal + 4‑Power Contacts, 2.0mm / 4.0mm Pitch, Jackscrew LockNegotiableMOQ: 5 Units -
M80‑5000000M1‑08‑331‑00‑000 HARWIN Connector, Vertical Through‑Board, 4.0mm Pitch, Internal‑Thread Jackscrew Lock, Datamate‑Power SeriesNegotiableMOQ: 5 Units
-
M80‑400000000‑06‑321‑00‑000, 6‑Pin SIL Female Connector 4.0mmNegotiableMOQ: 5 Units
-
Harwin M80‑5L10406M6‑04‑33‑00‑00 Datamate‑Mix‑Tek Signal+Power Mixed‑Layout High‑Reliability Connector, Jack‑Screw Locking, Gold‑Plated ContactsNegotiableMOQ: 5 Units
-
Harwin M80-4002606 6‑Pos Vertical Female Power Receptacle, 4.0 mm PitchNegotiableMOQ: 5 Units
Product Overview
M80‑5000000M1‑06‑335‑00‑000 is an original HARWIN Datamate‑Power high‑reliability male‑plug connector kit. It features 6‑position single‑row power contacts with 4.0mm pitch, fitted with internal‑thread floating jack‑screw locking structure for 12AWG heavy‑gauge cable soldering. Designed for high‑current power connection under severe vibration and shock conditions, this connector is widely used in industrial control, railway, medical equipment, telecom power, vehicle‑mounted and defense high‑reliability projects. The full kit contains housing plus 6 loose gold‑plated power contacts for convenient cable assembly, and can mate perfectly with the matching female receptacle.
Key Features
‑ Floating jack‑screw locking design, anti‑vibration, avoid unexpected power‑off caused by loose‑connection ‑ High‑current capacity, max. 20A per contact, compatible with 12 AWG heavy‑gauge wire ‑ Wide operating temperature:‑55℃ ~ +125℃, stable performance under extreme‑temperature environment ‑ Gold‑plated beryllium‑copper contacts, anti‑oxidation, low contact resistance, 500 mating cycles ‑ Glass‑filled PPS housing, UL94‑V‑0 flame‑retardant, high‑temperature resistant ‑ Free‑hanging cable‑mount design, solder termination, flexible wire‑to‑board power interconnection ‑ Matching female receptacle available for one‑stop‑procurement
Specifications
Manufacturer: HARWIN PN: M80‑5000000M1‑06‑335‑00‑000 Series: Datamate‑Power / Mix‑Tek Connector Type: Male Plug Number of Positions: 6 Power Contacts Pitch: 4.00 mm Locking: Internal‑Thread Floating Jackscrew Cable Termination: Solder Wire Gauge: 12 AWG Current Rating: Max. 20A per contact Contact Plating: Gold Contact Base Material: Beryllium Copper Housing Material: Glass‑filled PPS Flammability: UL94‑V‑0 Operating Temp:‑55℃ ~ +125℃ Mating Cycles: 500 RoHS: Lead‑Free Compliant Kit Contents: Housing + 6 loose power contacts
Applications
Industrial Control, Railway & On‑board Equipment, Medical Instrument, Telecom Power Supply, Defense & Aerospace, Industrial Robot & Automation Equipment
