Help CenterM80‑4000000F1‑06‑325‑00‑000 HARWIN Connector, Receptacle 6‑Position Power Female, 4mm Pitch, Jackscrew Lock, 12AWG, Datamate‑Power Series
Product Spotlights
2. 6‑position female receptacle, 4.0mm pitch, support 12AWG cable for high‑current transmission
3. Jack‑screw locking design, anti‑vibration, prevent accidental disconnection
4. Wire‑to‑board connection, easy wiring for industrial equipment
Related Products
-
M80‑5000000M1‑04‑335‑00‑000 HARWIN Connector, 4‑Position Male Plug, 4.0mm Pitch, Jackscrew Lock, 12AWG, Datamate‑Power Series Cable‑mount KitNegotiableMOQ: 5 Units -
M80‑5000000M1‑06‑335‑00‑000 HARWIN Connector, 6‑Position Male Plug, 4.0mm Pitch, Jackscrew Lock, 12AWG, Datamate‑Power Cable‑mount KitNegotiableMOQ: 5 Units
-
M80‑4T10405F1‑04‑321‑00‑000 HARWIN Datamate Mix‑Tek, 4‑Signal + 4‑Power Contacts, 2.0mm / 4.0mm Pitch, Jackscrew LockNegotiableMOQ: 5 Units
-
M80‑5000000M1‑08‑331‑00‑000 HARWIN Connector, Vertical Through‑Board, 4.0mm Pitch, Internal‑Thread Jackscrew Lock, Datamate‑Power SeriesNegotiableMOQ: 5 Units
-
M80‑400000000‑06‑321‑00‑000, 6‑Pin SIL Female Connector 4.0mmNegotiableMOQ: 5 Units
Product Overview
M80‑4000000F1‑06‑325‑00‑000 is an original HARWIN Datamate‑Power high‑reliability female receptacle connector kit. It features 6‑position single‑row power contacts with 4.0mm pitch, equipped with hex‑slotted floating jackscrews for secure locking. Rated for 12AWG heavy‑gauge cable, this connector delivers stable high‑current power transmission under severe vibration conditions, ideal for industrial, railway, medical, telecom, defense and vehicle‑mounted high‑reliability systems. The complete kit includes housing plus 6 loose gold‑plated power contacts for easy cable‑soldering assemblyHarwin.
Key Features
‑ Floating jack‑screw locking design, anti‑vibration & prevent accidental disconnection ‑ High‑current capacity, max.20A per contact, compatible with 12 AWG wire ‑ Wide operating temperature range:‑55℃ ~ +125℃ ‑ Gold‑plated brass contacts, low contact resistance, anti‑oxidation,500 mating cycles durability ‑ Glass‑filled PPS housing, UL94‑V‑0 flame retardant, high temperature resistance ‑ Free‑hanging wire‑to‑board connection, solder termination ‑ Matching male connectors available for one‑stop procurement
Specifications
Manufacturer: HARWIN PN: M80‑4000000F1‑06‑325‑00‑000 Series: Datamate‑Power Connector Type: Female Receptacle Number of Positions: 6 Power Contacts Pitch: 4.00 mm Locking: Hex‑Slotted Floating Jackscrew Cable Termination: Solder Wire Gauge: 12 AWG Current Rating: Max. 20A per contact Contact Plating: Gold Housing Material: Glass‑filled PPS Flammability: UL94‑V‑0 Operating Temp:‑55℃ ~ +125℃ Mating Cycles: 500 RoHS: Lead‑Free Compliant Kit Contents: Housing + 6 loose power contacts
Applications
Industrial Control, Railway & On‑board Equipment, Medical Instrument, Telecom Power Supply, Defense & Aerospace, Robot & Automation System
