Advanced Microwave Heating System for Wood Drying
Our Industrial Microwave Drying Machine is specially designed for the wood processing industry, providing efficient moisture removal for timber, lumber, wood panels, bamboo, veneers, flooring materials, and other wood products. Utilizing advanced microwave heating technology, the system delivers fast and uniform internal drying, helping manufacturers shorten production cycles and improve product quality.
Compared with conventional kiln drying, microwave drying heats moisture throughout the wood, which can significantly reduce drying time for suitable applications. The PLC-controlled continuous conveyor system ensures stable operation and can be customized to meet different production capacities and wood dimensions.
Key Features
Advanced microwave heating technology
Fast and uniform internal moisture removal
Continuous automatic drying process
PLC touch-screen intelligent control
Adjustable microwave power
Adjustable conveyor speed
High-efficiency drying performance
Energy-efficient operation
Continuous industrial production
Stable and reliable performance
Easy operation and maintenance
Customized equipment size and capacity
OEM & ODM manufacturing
CE-compliant design available
Suitable Materials
The machine is suitable for drying:
Timber
Lumber
Hardwood
Softwood
Wood Boards
Wood Panels
Plywood
Veneer
Bamboo
Engineered Wood
Wood Flooring
Furniture Components
Wood Pallets
Wooden Packaging Materials
Working Principle
Microwave energy penetrates deep into the wood and directly heats moisture within the material. Water evaporates from the inside outward, promoting faster and more uniform drying than many conventional surface-heating methods. Drying parameters can be adjusted according to wood species, thickness, moisture content, and production requirements.
Applications
Widely used in:
Wood processing plants
Lumber mills
Furniture manufacturers
Flooring production factories
Bamboo processing facilities
Wood packaging manufacturers
Engineered wood production lines
Building material manufacturers
Why Choose Our Microwave Wood Dryer?
Professional industrial microwave equipment manufacturer
Factory-direct pricing
Customized wood drying solutions
Advanced microwave heating technology
High automation and stable operation
Easy integration into existing production lines
Professional installation and commissioning
One-year warranty
Lifetime technical support
Exported to more than 100 countries and regions
FAQ
Q1: What types of wood can this machine dry?
It is suitable for hardwood, softwood, lumber, bamboo, plywood, veneer, engineered wood, pallets, and many other wood products.
Q2: Can the drying capacity be customized?
Yes. We customize microwave power, conveyor width, tunnel length, and production capacity according to your production requirements.
Q3: What are the advantages of microwave wood drying?
For suitable wood products, microwave drying can reduce drying time and improve moisture uniformity compared with many conventional drying methods. Performance depends on wood species, dimensions, and process settings.
Q4: Do you provide OEM & ODM services?
Yes. We offer customized machine design, private branding, voltage configuration, and complete turnkey drying solutions.
Technical Specifications:
Machine Model |
GS-20HMV |
GS-40HMV |
GS-60HMV |
GS-100HMV |
GS-200HMV |
Work Frequency |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
Rated Apparent Power |
≤25KW |
≤50KW |
≤75KW |
≤120KW |
≤240KW |
Output Power |
≥20KW |
≥40KW |
≥60KW |
≥100KW |
≥200KW |
Dehydration Capacity |
16-20kg/hour |
30-40kg/hour |
48-60kg/hour |
80-100kg/hour |
160-200kg/hour |
Work Process Temperature |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
Cooling Type |
Water Cool/Air Cool |
Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool |
Work Time |
24h Continuously Work |
24h Continuously Work | 24h Continuously Work | 24h Continuously Work | 24h Continuously Work |
Operation |
PLC & Touch Screen |
PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen |
Feeding Inlet Height |
40-100mm |
40-100mm | 40-100mm | 40-100mm | 40-100mm |
Belt Height |
60-1000mm |
60-1000mm | 60-1000mm | 60-1000mm | 60-1000mm |
Belt Running Speed |
0-4.5m/min or Customized |
0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized |
Belt Width |
500±100mm |
800±100mm |
800±100mm |
1000±100mm |
1200±100mm |
Belt Material |
Teflon Material or Customized |
Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized |
Size |
8640×1220×2200mm |
10960×1500×2200mm |
13200×1500×2200mm |
15600×1700×2200mm |
22560×1900×2200mm |
Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request
