AAAC BARE CONDUCTOR AS PER ASTM STANDARDS
1.1 AAAC-6201
All-Aluminum Alloy Conductor.
STANDARDS
AAAC-6201 bare conductor meets or exceeds the following ASTM standards:
l B-398 Aluminum-Alloy 6201-T81 Wire for Electrical Purposes.
l B-399 Concentric-Lay-Stranded 6201-T81 Aluminum Alloy Conductors.
CONSTRUCTION
Aluminum alloy 6201 wires. concentrically stranded.
|
Code word |
Size (kcmil) |
Strand-ing |
Diameter (ins.) |
Weight per 1000 ft. (Lbs) |
Rated strength (Lbs) |
Resistance /1000 ft. |
Allowable ampacity+ (Amps) |
ACSR with equiv.diam. |
Approx EC cond. with equivalent resistance |
|||
|
Indivi- dual wire |
Complete conductor |
DC at 20℃ |
AC at 75℃ |
Size |
Stranding (AL/STL) |
|||||||
Akron |
30.58 |
7 |
0.0661 |
0.198 |
28.5 |
1110 |
.659 |
.785 |
107 |
6 |
6/1 |
6 |
Alton |
48.69 |
7 |
0.0834 |
0.250 |
45.4 |
1760 |
.414 |
.493 |
143 |
4 |
6/1 |
4 |
Ames |
77.47 |
7 |
0.1052 |
0.316 |
72.2 |
2800 |
.260 |
.310 |
191 |
2 |
6/1 |
2 |
Azusa |
123.3 |
7 |
0.1327 |
0.398 |
115.0 |
4460 |
.163 |
.195 |
256 |
1/0 |
6/1 |
1/0 |
Anaheim |
155.4 |
7 |
0.1490 |
0.447 |
144.9 |
5390 |
.130 |
.154 |
296 |
2/0 |
6/1 |
2/0 |
Amherst |
195.7 |
7 |
0.1672 |
0.502 |
182.5 |
6790 |
.103 |
.123 |
342 |
3/0 |
6/1 |
3/0 |
Alliance |
246.9 |
7 |
0.1878 |
0.563 |
230.2 |
8560 |
.0816 |
.0973 |
395 |
4/0 |
6/1 |
4/0 |
Butte |
312.8 |
19 |
0.1283 |
0.642 |
291.7 |
11000 |
.0644 |
.0769 |
460 |
266.8 |
||
Crafted from premium 6101/6201 Al-Mg-Si alloy, AAAC delivers tensile strength up to 341MPa with 56.1%IACS conductivity, matching copper’s mechanical performance while eliminating hysteresis & eddy current losses for notable energy efficiency.
Excellent anti-corrosion property and superior sag performance suit long-span, high-altitude and coastal severe environments, with a 40-year service life far exceeding conventional ACSR.
Lightweight design cuts tower load and transport costs, ensuring stable installation connection. It meets ASTM B399, IEC 61089 standards, supporting continuous operation at 90℃ (heat-resistant type up to 150℃) for global power grid projects.
