Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 with a factory size of 10,000-30,000 square meters and annual export value of US$10-50 million, is proud to present our Multi-effect Evaporation Concentration Crystallizer with Mill Test Report. Crafted from premium 316L stainless steel and equipped with advanced PLC control, this equipment is designed for efficient and reliable concentration and crystallization of various solutions. Our crystallizer combines multi-effect evaporation technology with precise automation, ensuring high recovery rates, low energy consumption, and consistent product quality. Trusted by clients across North America, South America, Europe, and Asia, this solution is ideal for industries requiring robust evaporation and crystallization processes.
Key Features and Technical Specifications
- Multi-effect Evaporation Design: Utilizes multiple stages to maximize heat recovery, reducing steam consumption by up to 60% compared to single-effect systems.
- 316L Stainless Steel Construction: Excellent corrosion resistance for handling acidic, alkaline, and saline solutions; suitable for food, pharmaceutical, and chemical applications.
- PLC Control System: Fully automated operation with touchscreen interface, real-time monitoring of temperature, pressure, flow rate, and concentration levels. Supports remote control and data logging.
- Mill Test Report Included: Every unit is supplied with a certified mill test report for material traceability, ensuring compliance with quality standards.
- High Crystallization Efficiency: Dedicated crystallizer section with forced circulation or scraped surface design for uniform crystal growth and easy solid-liquid separation.
- Energy Saving: Thermal vapor recompression (TVR) or mechanical vapor recompression (MVR) options available upon request.
- Customizable Capacity: Available in evaporation capacities from 1,000 L/h to 50,000 L/h, tailored to specific customer needs.
| Parameter | Specification |
|---|---|
| Material | 316L Stainless Steel (SS316L) |
| Evaporation Effect | 2-7 effects (customizable) |
| Control System | PLC + HMI (Siemens/Mitsubishi/Omron optional) |
| Operating Temperature | Up to 150°C (depending on solution) |
| Vacuum Range | -0.09 to -0.05 MPa |
| Power Supply | 380V/50Hz (or as per local standard) |
| Application | Industrial wastewater, brine, chemical solutions, pharmaceutical intermediates |
Detailed Product Advantages
- Enhanced Efficiency: The multi-effect design significantly reduces energy consumption, lowering operational costs for your facility.
- Corrosion Resistance: 316L stainless steel ensures long service life even when processing aggressive media, minimizing maintenance downtime.
- Precision Control: PLC automation allows for consistent product quality, automatic fault detection, and easy integration into existing plant systems.
- Quality Assurance: Each unit is factory-tested and comes with a complete mill test report, providing full material traceability and peace of mind.
- Versatility: Suitable for a wide range of feed solutions, including high-salinity wastewater, chemical mother liquor, and heat-sensitive materials.
- Compact Footprint: Skid-mounted design saves floor space and simplifies installation.
Trust and Reliability
As a manufacturer with over 200 employees and a factory spanning 10,000-30,000 square meters, Qingdao Conqinphi Environmental Technology Group has delivered equipment to markets worldwide. Our company holds multiple management system certifications including ISO9001, ISO14000, OHSAS18001, SA8000, and others, reflecting our commitment to quality, environmental responsibility, and social accountability. With an annual export value exceeding US$10 million, we have built a strong reputation among clients in North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our crystallizer is backed by comprehensive after-sales support, including installation guidance, commissioning, and remote troubleshooting. Choose our Multi-effect Evaporation Concentration Crystallizer to achieve efficient, sustainable, and profitable operation for your evaporation and crystallization needs. Contact us today for a tailored solution.
Frequently Asked Questions (FAQ)
- What is the difference between multi-effect and single-effect evaporation? Multi-effect systems reuse vapor from one effect as heating medium for the next, drastically reducing steam consumption. Our crystallizer can achieve up to 60% energy savings.
- Can this crystallizer handle high-viscosity solutions? Yes, we offer optional forced circulation or scraped surface designs to maintain efficient heat transfer and crystallization even with viscous feeds.
- Is the PLC control compatible with remote monitoring? Yes, the standard PLC system supports remote access via Ethernet or optional SCADA integration, allowing you to monitor and adjust parameters from a central control room.
- What certifications does the equipment have? The equipment is manufactured under ISO9001 and ISO14000 certified facilities. We provide a mill test report for 316L material, and can also supply pressure vessel certificates if required.
- What is the typical delivery time? Delivery time depends on capacity and customization level, usually ranging from 8 to 16 weeks. Contact our sales team for a precise schedule.
- Do you provide installation and commissioning services? Yes, we offer on-site installation supervision and commissioning support. Training for operators is also available.
- Can the crystallizer be used for zero liquid discharge (ZLD) systems? Absolutely, this equipment is a core component in many ZLD processes, effectively concentrating wastewater and recovering valuable solids.
- What is the warranty period? We offer a standard 12-month warranty from the date of commissioning, with extended warranty options available upon request.
