As a leading manufacturer in the renewable energy sector, Qingdao Conqinphi Environmental Technology Group is proud to present our advanced Plate Aluminum Roll Bond Evaporator, a core component engineered for superior performance in solar water heating systems. With our foundation built on years of specialized manufacturing since 2015 and a sprawling facility spanning 10,000-30,000 square meters, we deliver products that embody reliability, efficiency, and innovation. This evaporator is designed to maximize heat absorption and transfer, directly translating to higher hot water output and energy savings for your projects. We cater to a global clientele across North America, Europe, Asia, and beyond, ensuring our solutions meet diverse climatic and application demands.
Product Features & Technical Advantages:
Our CONQINPHI Roll Bond Evaporator stands out due to its unique construction and optimized design. The roll bond manufacturing process creates a continuous, leak-proof internal channel pattern within a single aluminum plate, eliminating the need for mechanical joints that can be potential failure points. This results in a highly durable and efficient heat exchanger core.
- Superior Heat Transfer: The large, flat surface area of the aluminum plate and the optimized internal fluid channels ensure rapid and uniform heat absorption from solar radiation, leading to faster water heating.
- Exceptional Durability: Made from high-grade aluminum alloy, the evaporator is highly resistant to corrosion and can withstand long-term exposure to various weather conditions, ensuring a long service life.
- Lightweight & Flexible Design: Aluminum construction makes the unit lightweight for easier handling and installation. The roll bond plate can be customized into various shapes and sizes to fit different solar collector designs.
- High System Efficiency: By minimizing thermal resistance and pressure drop within the channels, our evaporator contributes to the overall higher efficiency of the solar thermal system, improving the return on investment.
Key Technical Specifications:
The following table outlines some common parameters for our standard evaporator plates. Please note that specifications can be customized based on your specific system requirements.
| Parameter | Typical Value / Description |
| Core Material | High-grade Aluminum Alloy (e.g., 3003/3005) |
| Standard Plate Thickness | 0.4mm - pp1.0mm (customizable) |
| Channel Design | Serpentine or parallel flow patterns (optimized for low pressure drop) |
| Working Fluid | Compatible with water, glycol mixtures, or other heat transfer fluids |
| Max Working Pressure | Typically up to 1.0 MPa (customizable) |
| Surface Finish | Natural aluminum or optional selective coating for enhanced absorption |
Benefits for Your Business:
- Enhanced Product Performance: Integrate a high-efficiency core component to boost the overall performance of your solar water heaters, giving you a competitive edge in the market.
- Reduced Assembly Complexity: The one-piece roll bond design simplifies your production line assembly compared to traditional tube-and-fin systems.
- Reliability & Lower Maintenance: The robust, leak-resistant design minimizes the risk of system failure and reduces long-term maintenance costs for end-users.
- Customization Flexibility: We work closely with clients to tailor the size, port configuration, and channel layout to seamlessly integrate into your specific collector design.
Backed by our commitment to stringent quality control reflected in our ISO9001 and ISO14001 certifications, and supported by an annual export value ranging between US$10-50 million, Qingdao Conqinphi has established itself as a trusted partner for global solar thermal projects. Our evaporator is not just a component; it's a cornerstone for building efficient and durable solar water heating systems. With direct shipment from the port of Qingdao and experience serving markets worldwide, we ensure timely delivery and reliable support. Choose CONQINPHI for a component that enhances system value and performance. Contact us today to discuss your requirements or request samples for testing.
Frequently Asked Questions (FAQ)
-
Q: What is the main advantage of a roll bond evaporator over a traditional tube-and-fin type?
A: The roll bond process forms the fluid channels directly within a single aluminum plate, creating a seamless, monolithic unit. This eliminates brazed or mechanical joints, significantly reducing the risk of leaks and improving structural integrity and heat transfer contact. -
Q: Can you customize the size and shape of the evaporator plate?
A: Yes, customization is a key service we offer. We can produce plates in various dimensions and can adapt the internal channel layout to match your solar collector's specific design and thermal performance goals. -
Q: What heat transfer fluids are compatible with this aluminum evaporator?
A: The standard aluminum alloy is compatible with water and propylene glycol/water mixtures commonly used in solar thermal systems. For other fluids, please consult with our technical team to ensure material compatibility. -
Q: How does the aluminum material hold up against corrosion?
A: We use high-grade aluminum alloys known for their natural corrosion resistance. For applications in more aggressive environments or with specific fluids, we can discuss optional surface treatments or alloy selections. -
Q: What is the typical lead time for an order?
A: Lead time depends on order quantity and customization level. For standard specifications, production is efficient. We provide specific timelines upon receipt of your detailed inquiry. -
Q: Do you provide performance test data or certificates for your products?
A: Yes, we can provide relevant performance data sheets. Our manufacturing process adheres to ISO9001 quality management standards, ensuring consistent product quality. -
Q: What are the port connection options available?
A: We offer various port types (e.g., threaded, barbed) and configurations (location, size). This is a customizable aspect to ensure easy integration with your system's piping. -
Q: Is a selective coating available to improve solar absorption?
A: While the standard finish is natural aluminum, an optional selective coating can be applied to the plate surface to significantly increase solar absorptivity and reduce heat loss, enhancing overall efficiency.
