Mining cables G-GC 2KV-5KV
· Flame retardant, compliant with IEC 60 332 part 1
· Oil-resistant, moisture-resistant, low-wear, scratch-resistant, torsion-resistant and ozone-resistant
· UV-resistant
· Customization is acceptable for products with special structures, other sizes, and colors of cores and sheaths.
Due to the good environmental tolerance and flexibility of this product, it is mainly used in equipment that requires frequent mobile operations in the mining industry, such as material cranes, electric shovels, electric drills, and excavators. For example: ATLAS EST3.5 load-haul-dump machines and other equipment.
Conductor: There is a tinned copper mixed braided shield outside the three-phase wires, which greatly enhances the flexibility of the cable.
Insulator: EPDM insulating rubber, which has excellent electrical properties. It can still maintain good flexibility even at low temperatures, is resistant to chemical corrosion, and is ozone-proof.
Ground wire: Soft bare copper without tin and insulation.
Outer sheath: Heavy-duty polyvinyl chloride (CPE), which enhances environmental tolerance, is resistant to chemical corrosion, oxygen-proof, and flame retardant.
Rated voltage: 2KV-5KV
Conductor resistance: Compliant with IEC 60228 standard
Temperature range: -45°C to +100°C
Flame retardant rating: IEC 60332-1-2
Standard: ICEA S-75-381
Product identification: Aein beiKe SHANGHAI AEIN WIRE& CABLE CO.LTD Model Specification Voltage CE Meter mark
· Compliant with RoHS standard
· Compliant with 2014/35/EU - Directive 《Low Voltage Directive》 CE.
Our Advantages
Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch has a modern production base integrating production, quality inspection, and development. The entire process of the company's production and operation is strictly in line with the requirements of the ISO9001:2000 Quality Management System standard to implement comprehensive quality control, thus ensuring the product quality. The products produced by our company all meet international standards and can directly replace foreign products. It allows you to own products of international level at a reasonable price.
The main products produced by our company are: Drag chain cables, robot cables, servo cables, braider cables, highly flexible control cables, UL-certified cables, EAC customs-certified cables, CE-certified cables, SAA Australian standard-certified cables, TUV German standard-certified cables, Japanese standard cables, crane cables, reel cables, signal cables, hoist cables, oil-resistant cables, cold-resistant cables, bucket wheel machine cables, overhead traveling crane cables, marine cables, zero-buoyancy cables, Armored cables, RS-485, corrosion-resistant, acid and alkali-resistant cables, control cables, BUS cables, national standard CCC cables, PUR polyurethane cables, Self-supporting steel cable cables, elevator cables, cables for electrical installation, Special cables, etc. After years of development, our company has been recognized by a large number of users with good reputation and high-quality products.
