Product Introduction

01 Product Applications

For exposed wiring and conduits (except cable trays) in wet and dry locations, as well as lighting, power systems, and general wiring applications. With appropriate handling procedures, the recommended minimum installation temperature is -40°C. Cables marked with SUN RES are also suitable for outdoor use and wiring exposed to the weather. It can replace CUL-certified R90 model products.

02 Product Features

-40°C cold bending and -40°C cold impact

Low smoke and zero halogen

Sunlight resistance

03 Technical Certifications

Complies with RoHS standards

CSA c22.2.No38

UL44

Product Structure

Conductor material: Bare copper or tinned copper is optional

Conductor type: Complies with UL44 standards, meets the requirements of ASTM B3, B8, B33, or NMX-J-008-ANCE

Insulation material: XLPE

Insulation color: Optional

Rated voltage: 600V, 1000V, 2000V

Operating temperature: -40°C to +90°C

Conductor resistance: UL1581 ASTM Class C

Minimum bending radius for fixed installation: 7.5x outer diameter (d)

Minimum bending radius for mobile installation: 15x outer diameter (d)

Flame retardant rating: Self-extinguishing and flame retardant properties comply with UL1581 VW-1; CSA C22.2 No.2556-15 FT1, FT2; IEC 60332-1-2 standards

Certifications: UL, CSA




Product Tags: CSA-certified cables , Lighting wiring , Sun-resistant , Low-smoke zero-halogen cables , Cold-resistant cables
