Product Introduction

01 Product Applications

The cable can be used for power supply, control, and connection in power facilities. It can be fixedly laid or moved freely. The cable does not bear large tensile stress. The cable can be used in dry, damp, and wet indoor environments (including areas with water-oil mixtures). Data transmission, control, and connection cables are mainly used for the transmission of analog and digital signals in process control facilities in measurement and control technology. They are suitable for fixed laying and flexible applications, without a clear cable path and without tensile stress. They are suitable for use in dry and wet indoor environments. This cable is specially designed for industrial facilities and urban network power distribution systems with a rated voltage of 0.6/1kV and a frequency of 50HZ. It is suitable for indoor fixed installation, laid in cable ducts, cable trays, directly buried in trenches, or used in outdoor environments with protection.

02 Product Features

Black type sheath: Can be used for UV resistance

Flame retardancy

03 Technical Certifications

Complies with RoHS standards

Complies with 2014/35/EU - Directive ("Low Voltage Directive") CE

Product Structure

Conductor material: Bare copper wire

Conductor class: Complies with IEC 60228 cl.5 standard

Insulation: XLPE

Core wire identification: Black core wire with white numbers, with or without GNYE

Stranding: Layered stranding

Outer sheath: PVC

Sheath color: Black, RAL9005 or gray RAL7001

Rated voltage: 0.6/1kV

Test voltage: 4kV

Conductor resistance: Complies with IEC60228cl.5 standard

Capacitance: Core/core approximately 120 nF/km; Core/shield approximately 160 nF/km

Minimum bending radius: 7.5xd

Minimum bending radius: 15xd

Temperature rating for fixed use: -15°C/+90°C

Temperature rating for mobile use: -5°C/+90°C

Flame retardant rating: IEC60332-1-2

Standards: HD 603-3G IEC60502

Product identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO.LTD Model Specification Voltage CE Meter mark




Product Tags: TUV cables , Indoor installation cables , UV-resistant cables , Power cables , Flame-retardant cables
