Product Introduction
01 Product Application
This cable can be laid on the upper, middle and lower layers of plaster concrete; it can be fixedly installed indoors, outdoors or in concrete; it is used in buildings or industrial buildings where people or valuable items are concentrated; it cannot be directly buried or installed in water; it can only be laid outdoors when protected from direct sunlight and other external influences.
02 Product Features
The flame retardancy complies with IEC60332-1-2.
The non-flammable performance complies with IEC 60332-3-24.
It is halogen-free and complies with IEC60754-1 (total amount of halogen acid gas).
The corrosiveness of combustion gas complies with IEC60754-2 (acidity).
It has low smoke density and complies with IEC61034-2.
03 Technical Certification
It complies with the RoHS standard.
It complies with the 2014/35/EU - Directive ("Low Voltage Directive") CE.
Product Structure
Conductor material: Bare copper wire
Conductor type: Complies with IEC60228 cl.5 standard
Core insulation: XLPE
Core identification: Black cores with white numbers, with or without GNYE
Stranding: Layered stranding.
Shielding layer: Tinned copper wire braiding
Sheath: Halogen-free, thermoplastic polyolefin mixture
Outer sheath color: Black, RAL9005 or gray RAL7001
Rated voltage: 0.6/1kV
Test voltage: 4kV
Conductor resistance: Complies with IEC60228 cl.5 standard
Minimum bending radius for fixed installation: 7.5xd
Minimum bending radius for mobile installation: 15xd
Temperature rating for fixed installation: -15°C/+90°C
Temperature rating for mobile installation: -5°C/+90°C
Flame retardant rating: IEC60332-1-2
Standards: HD603-3G IEC60502
Product marking: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO,LTD Model Specification Voltage CE Meter mark
