Product Introduction
01 Product Applications
These cables for power distribution are suitable for all types of low-voltage industrial connections, urban power grids, building facilities, etc. They are especially suitable for situations with high operating temperatures and where high resistance to solar radiation and atmospheric media is required. They have good low-temperature resistance and chemical resistance.
02 Product Features
The flame retardancy meets IEC 60332-1-2.
Customization is acceptable for products with special structures, other sizes, and colors of cores and sheaths.03 Technical Certifications
Complies with RoHS.
Complies with 2014/35/EU-Guideline ("Low Voltage Directive") CE.
Complies with TUV certification.
Product Structure
Conductor material: Bare copper wire
Conductor class: Complies with IEC 60228 cl. 5 standard, cl. 2 is optional
Insulation: XLPE
Core identification: Two cores: red and blue; Three cores: red, yellow, and green; Four cores: red, yellow, green, and blue; Five cores: red, yellow, green, blue, and yellow/green
Stranding: Layered stranding
Outer sheath: PVC
Sheath color: Black, RAL 9005 or gray RAL 7001
Rated voltage: 0.6/1kV
Test voltage: 3.5kV
Conductor resistance: Complies with IEC 60228 cl. 5 standard
The rated temperature of the cable conductor is: 90 °C
During short-circuit (duration no more than 5s), the temperature of the cable conductor does not exceed 250 °C
Minimum bending radius (fixed): 7.5 x d
Minimum bending radius (mobile): 15 x d
Temperature class (fixed): -15 °C / +90 °C
Temperature class (mobile): -5 °C / +90 °C
Flame retardant class: IEC 60332-1-2
Standard: HD 603-3G IEC60502
Product identification: Aein bei ke SHANGHAI AEIN WIRE ＆ CABLE CO.,LTD Model, Specification, Voltage CE Meter mark
