Product Introduction
01 Product Applications
Certified and specifically designed for industrial equipment, heavy tools, motors and welding leads, power extensions, portable machinery, audio equipment, portable stage lights, ship dock power supply, and mining applications. Suitable for indoor/outdoor use.
02 Product Features
Excellent resistance to oil, acids, chemicals, water, ozone, extreme temperatures, cutting, tearing, and abrasion. S = Service line (600V)
J = Primary service line (300V)
03 Technical Certifications
Complies with UL62
Complies with CSA C22.2-49
Complies with RoHS
UL/CSA certified
Customization is acceptable for products with special structures, other sizes, and colors of cores and sheaths.
Product Structure
Conductor material: Copper stranded wire
Conductor class: Complies with DIN VDE 0295 Class 5, referring to IEC 60228 Class 5
Core insulation: EP
Core identification: Preferred colors: Black, white, red, yellow-green (green), orange. From 6 black RAL 9005 wires with white numbers, with or without yellow/green.
Stranding: Core layer stranding with fillers
Outer sheath: EP
Outer sheath color: Black RAL 9005 (optional)
Rated voltage: 300V
Test voltage: 18AWG - 11AWG 2000V; 10AWG 3000V
Minimum bending radius for fixed use: 7.5xd
Minimum bending radius for mobile use: 10xd
Working temperature for fixed use, minimum/maximum: --40°C/+105°C -40°C/+90°C -40°C/+75°C -40°C/+60°C. Temperature grade for mobile use, minimum/maximum: --40°C/+105°C -40°C/+90°C -40°C/+75°C -40°C/+60°C. Flame retardant grade: Self-extinguishing and flame retardant, complies with IEC 60332-1-2 FT1 VW-1
Oil resistance: Complies with EN 60811-2-1
Certifications: CE: H07RN-F, H07BN4-F, H07RN8-F. If CE certification is required, it needs to be specified separately.
Product identification: Aein bei ke E503806 (UL) Model *x* AWG (*mm2) Temperature and voltage c (UL) Model *x* mm2 (*AWG) Temperature and voltage FT2
