Product Introduction
01 Product Application
Used for power, control, and connection cables in power facilities, as well as for data and signal transmission. The installation methods include fixed laying and mobile laying, with no clear cable path and no tensile stress. The cables are suitable for dry, damp, and wet indoor environments.
02 Product Features
Complies with RoHS
Complies with 2014/35/EU - Guideline ("Low Voltage Directive") CE
Customization is acceptable for products with special structures, other sizes, and colors of core wires and sheaths.
03 Technical Certification
Complies with RoHS standards
Complies with 2014/35/EU - Guideline ("Low Voltage Directive") CE
Flame retardancy complies with IEC 60332 - 1 - 2
Product Structure
Conductor material: Bare copper wire
Conductor class: Complies with IEC60228 cl.5 standard
Insulation: PVC
Core wire identification: Black core wire with white numbers, with or without GNYE
Stranding: Layered stranding
Shielding: Concentric conductor (braided)
Outer sheath: PVC
Sheath color: Black, RAL9005 or gray RAL7001
Rated voltage: 0.6/1kV
Test voltage: 4kV
Conductor resistance: Complies with IEC 60228cl.5 standard
Minimum bending radius: 7.5xd
Minimum bending radius: 15xd
Temperature rating (fixed): -15°C/+70°C
Temperature rating (mobile): -5°C/+70°C
Flame retardant rating: IEC60332 - 1 - 2
Standards: HD 603 - 3G IEC60502
Product identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO.LTD Model Specification Voltage CE Meter mark
