Help CenterSS316L Multi-effect Evaporation Crystallization Equipment With PLC Automatic Control, 500-5000 L/h Capacity for Industrial Use
Product Spotlights
Related Products
-
Multi-effect Evaporation Crystallization System With 2-Year Warranty, Free Technical Training and Installation GuidanceUS$ 6870 - 86900MOQ: 1 Combo -
Standard-Compliant Multi-Effect Evaporator With Remote Monitoring and Technical Support PackageUS$ 5470 - 768000MOQ: 1 Combo
-
Multi-Effect Evaporator for Pharmaceutical and Chemical Processing With CIP SystemUS$ 5470 - 768000MOQ: 1 Combo
-
Customized Multi-Effect Evaporator With Automatic Control for Food and Beverage IndustryUS$ 5470 - 768000MOQ: 1 Combo
-
High-Efficiency Multi-Effect Evaporator System With MVR Technology for Energy SavingsUS$ 5470 - 768000MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 with a 10,000-30,000 m² factory and over 200 skilled employees, proudly presents our SS316L Multi-effect Evaporation Crystallization Equipment. Designed for industrial-grade performance, this system combines high-grade stainless steel construction with advanced PLC automatic control, delivering reliable and energy-efficient evaporation and crystallization for demanding applications such as wastewater treatment, chemical concentration, and brine recovery. With a flexible capacity range of 500 to 5,000 L per hour, it adapts seamlessly to varying production scales while minimizing operational costs.
Product Highlights & Technical Specifications
- Material Excellence: All wetted parts are made from SS316L stainless steel, offering excellent corrosion resistance against acids, alkalis, and chlorides, ensuring long service life even under harsh conditions.
- Energy-Efficient Multi-effect Design: The multi-effect evaporation principle reuses vapor from one effect as heating medium for the next, achieving steam savings of up to 70% compared to single-effect systems. Typical steam consumption ranges from 0.2 to 0.4 kg steam per kg of water evaporated, depending on the number of effects (e.g., 3-effects, 4-effects).
- PLC Automatic Control: Equipped with a Siemens or equivalent PLC system, the equipment automatically monitors and adjusts parameters such as temperature, pressure, liquid level, and flow rate. Touch-screen interface provides intuitive operation, real-time data display, and alarm functions, reducing manual intervention by over 80%.
- Capacity Flexibility: The standard model covers 500-5,000 L/h water evaporation capacity. Custom designs are available for higher or lower capacities upon request. The system can handle feed concentrations from 1% to 35% total dissolved solids (TDS).
- Compact Footprint: Multi-effect design significantly reduces floor space requirements. A typical 2,000 L/h system occupies approximately 80 m², making it ideal for both greenfield and retrofit projects.
- Easy Maintenance: Modular construction allows quick access to each effect for inspection and cleaning. The SS316L surface is smooth and resistant to scaling, reducing maintenance frequency.
Technical Parameters (Typical 2000 L/h Model)
| Parameter | Value |
| Evaporation Capacity | 2,000 L/h |
| Number of Effects | 3 (optional 4-5 effects) |
| Evaporation Temperature | First effect: 100-120°C, Final effect: 50-70°C |
| Power Supply | 380V/50Hz, three-phase (customizable) |
| Steam Consumption | ~0.35 kg steam / kg water |
| Control System | PLC (Siemens) + HMI touch screen |
| Material of Construction | SS316L (body, tubes, separator) |
| Overall Dimensions (L×W×H) | 12m × 5m × 6m (approx.) |
Beyond the technical specifications, our equipment delivers tangible benefits: reduced energy bills thanks to the multi-effect design, minimal operator workload through PLC automation, and consistent product quality even with fluctuating feed conditions. The SS316L material also eliminates product contamination risks, making it suitable for food-grade and pharmaceutical-grade crystallization applications. Furthermore, the system is designed with safety features such as overpressure protection, emergency stop, and automatic shutdown on abnormal conditions.
As a testament to our reliability, Qingdao Conqinphi has an annual export value of US$10-50 million, serving markets across North America, Europe, Southeast Asia, Africa, and Oceania. Our factory holds multiple certifications including ISO9001, ISO14000, OHSAS18001, HACCP, and SA8000, reflecting our commitment to quality, environment, health, and social responsibility. With over 200 employees dedicated to R&D, manufacturing, and after-sales service, we ensure prompt technical support, spare parts availability, and customizable solutions. We invite you to contact us for a detailed quotation or to schedule a factory visit – let our expertise become your competitive advantage.
Frequently Asked Questions (FAQ)
-
Q: What is the main advantage of the SS316L material in this equipment?
A: SS316L offers superior corrosion resistance to chlorides and acids, making it ideal for treating high-salinity wastewater, acidic streams, and brine solutions. It also meets hygienic standards required in pharmaceutical and food industries. -
Q: Can the PLC system be integrated with existing plant DCS or SCADA?
A: Yes, the PLC supports common communication protocols such as Modbus, Profibus, and Ethernet/IP, allowing seamless integration with your existing control network. We can also customize the HMI interface per your requirements. -
Q: What is the typical energy consumption for a 2000 L/h system?
A: For a 3-effect system, the steam consumption is approximately 0.35 kg steam per kg of water evaporated, and the electrical consumption is around 5-10 kW for pumps and controls. This results in up to 70% energy savings compared to single-effect evaporators. -
Q: How often does the equipment need maintenance?
A: Routine inspection every 1-2 months is recommended, focusing on seals, pumps, and control components. Major cleaning may be required every 6-12 months depending on scaling tendency. The SS316L surface minimizes scaling, extending intervals. -
Q: What is the minimum space required for installation?
A: The footprint varies with capacity. For a 1000 L/h unit, approximately 50 m² is needed. Our engineering team will provide a detailed layout drawing after reviewing your site conditions. -
Q: Do you offer training for operators?
A: Yes, we provide comprehensive training at your site or in our factory, including PLC operation, troubleshooting, and preventive maintenance. Manuals and video tutorials are also supplied. -
Q: What kind of after-sales warranty do you provide?
A: Standard warranty is 12 months from commissioning or 18 months from shipment, whichever comes first. Extended warranty options are available upon request. We also maintain a global network of service partners for rapid support.
