High-Efficiency Multi-Effect Evaporator System With MVR Technology for Energy Savings
Product Spotlights
This advanced evaporator combines multi-effect staging with Mechanical Vapor Recompression (MVR) to deliver exceptional energy efficiency, reducing operational costs significantly. Built with corrosion-resistant materials and automated PLC controls, it ensures reliable, low-maintenance operation for wastewater concentration, ZLD projects, and product recovery in chemical, food, and pharmaceutical industries.
US$ 5470 - 768000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Application:
Other, Wastewater Treatment
Technology:
Mechanical Vapor Recompression (MVR)
Evaporation Type:
Multi-Effect Evaporator System
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days
Related Products
-
304 Stainless Steel Multi-Effect Evaporator With PLC Control for Industrial ConcentrationUS$ 5470 - 768000MOQ: 1 Combo -
Multi-Effect Evaporator With 316L Stainless Steel Construction for Corrosive LiquidsUS$ 5470 - 768000MOQ: 1 Combo
-
Multi-Effect Evaporator for Dairy and Sugar Concentration With Mill Test Report ProvidedUS$ 5470 - 768000MOQ: 1 Combo
-
Multi-Effect Evaporator System Featuring Falling Film Design and Heat RecoveryUS$ 5470 - 768000MOQ: 1 Combo
-
Multi-Effect Evaporator for Pharmaceutical and Chemical Processing With CIP SystemUS$ 5470 - 768000MOQ: 1 Combo
Application
Other, Wastewater Treatment
Technology
Mechanical Vapor Recompression (MVR)
Evaporation Type
Multi-Effect Evaporator System
Key Feature
High Efficiency & Energy Saving
Construction Material
Stainless Steel 304/316L (Customizable)
Control System
PLC-based Automatic Control (Optional)
Design Standard
Customizable to Client Specifications
Capacity Range
Available upon request
Heat Source
Electricity (MVR) or Optional Steam
As a leading manufacturer with nearly a decade of experience, Qingdao Conqinphi Environmental Technology Group is proud to introduce our advanced High-Efficiency Multi-Effect Evaporator System integrated with MVR (Mechanical Vapor Recompression) Technology. Engineered for industries prioritizing operational cost reduction and environmental responsibility, this system represents a significant leap in evaporation technology. We combine robust manufacturing capabilities from our 10,000-30,000 sqm facility with stringent quality management systems to deliver reliable, high-performance evaporation solutions that directly address the global need for energy conservation and sustainable wastewater management.
The core innovation of our system lies in the seamless integration of multi-effect evaporation with MVR. This hybrid design maximizes energy efficiency by reusing the latent heat of vaporization across multiple stages (effects) and then further boosting the thermal efficiency by mechanically compressing the vapor from the final effect. The result is a closed-loop system that drastically reduces, and in many cases eliminates, the need for external fresh steam, leading to substantial operational savings.
Detailed Product Features & Technical Advantages:
- Superior Energy Efficiency: The MVR compressor is the heart of the system. It recompresses low-pressure vapor, raising its temperature and pressure so it can be reused as a heating medium. This process can reduce energy consumption by up to 90% compared to traditional single-effect evaporators and offers significant savings over conventional multi-effect systems without MVR.
- Multi-Effect Design for Maximum Heat Recovery: The evaporator consists of multiple "effects" or stages. Vapor generated in one effect serves as the heat source for the next, creating a cascading energy recovery process. When coupled with MVR, the overall thermal efficiency is exceptionally high.
- Robust and Corrosion-Resistant Construction: Key components, including heat exchangers, separators, and piping, are typically constructed from high-grade stainless steel (SS304 or SS316L) to ensure longevity when handling corrosive or aggressive process liquors. Material selection is customizable based on your specific feed solution.
- Fully Automated PLC Control System: The entire evaporation process—from feed flow and concentration control to compressor operation and CIP (Cleaning-in-Place)—can be managed through an intuitive PLC-based interface. This ensures stable operation, consistent product quality, and reduced labor costs.
- Compact and Modular Design: Our systems are engineered for optimal footprint, making them suitable for both greenfield projects and retrofits into existing plants. The modular approach also facilitates easier transportation and installation.
- Versatile Application Scope: This system is ideal for zero liquid discharge (ZLD) projects, concentration of inorganic/organic solutions, wastewater volume reduction, and recovery of valuable products from process streams in industries such as chemicals, pharmaceuticals, food & beverage, and environmental treatment.
Technical Specifications Overview:
| Parameter | Description / Typical Range |
|---|---|
| Evaporation Capacity | Customizable from 500 kg/hr to 50 tons/hr and beyond |
| Number of Effects | 2 to 4 effects (configurable based on energy goals) |
| Final Concentration | Can achieve high solid content, suitable for crystallization |
| MVR Compressor Type | Centrifugal or Roots blower, selected for optimal efficiency |
| Heat Transfer Area | Designed per client's capacity and duty requirements |
| Control Philosophy | Fully automatic with PLC, SCADA interface optional |
Tangible Benefits for Your Business:
- Drastic Reduction in Operating Costs: The primary benefit is the dramatic decrease in energy consumption, which translates directly into lower utility bills and a faster return on investment.
- Environmental Compliance and Sustainability: Enables effective wastewater minimization, supports Zero Liquid Discharge (ZLD) initiatives, and reduces your plant's carbon footprint.
- High Product Quality and Yield: Gentle evaporation under vacuum conditions helps preserve heat-sensitive components, which is crucial for food and pharmaceutical applications, while maximizing product recovery.
- Operational Reliability and Low Maintenance: Built with quality components and designed for continuous operation, the system ensures high uptime and requires minimal routine maintenance.
Backed by Conqinphi's commitment to quality evidenced by our ISO9001, ISO14000, and OHSAS18001 certifications, and supported by our experience serving a global clientele across North America, Europe, Asia, and beyond, you can trust in the reliability and performance of our evaporator systems. Our annual export value of US$10-50 million underscores our capability to execute international projects efficiently. We invite you to leverage our expertise to design a tailored High-Efficiency MVR Multi-Effect Evaporator System that meets your precise capacity, concentration, and energy-saving targets. Contact our engineering team today for a detailed feasibility analysis and quotation.
Frequently Asked Questions (FAQ):
-
Q: How does the MVR technology achieve such high energy savings?
A: MVR uses a mechanical compressor to recycle vapor. Instead of condensing and discarding the vapor's latent heat, the compressor increases its temperature and pressure, allowing it to be reused as the primary heat source. This recycling drastically cuts the need for external steam or cooling water. -
Q: Is this system suitable for my specific industry and wastewater stream?
A: Our systems are highly adaptable. We conduct a thorough analysis of your feed composition (salts, organics, pH, scaling potential) to recommend the optimal design, material selection, and pre-treatment if necessary. Please share your feed specifications for a tailored proposal. -
Q: What is the typical payback period for this investment?
A: The payback period depends heavily on local energy costs (electricity vs. steam) and your current evaporation expenses. Typically, the significant reduction in energy consumption leads to payback periods ranging from 1 to 3 years. -
Q: Can the system handle high fouling or scaling feed solutions?
A: Yes. We incorporate design features such as forced circulation, anti-scaling crystal slurry circulation, and effective CIP systems to manage scaling. Material selection also plays a key role in mitigating fouling. -
Q: Do you provide automation and remote monitoring capabilities?
A> Absolutely. A standard PLC-based control system is included for automatic operation. Options for remote monitoring via SCADA or IoT platforms are available, allowing for off-site performance tracking and troubleshooting. -
Q: What after-sales support do you offer?
A> We provide comprehensive support including detailed installation guidance, operator training, a warranty period, and readily available spare parts. Our technical team is accessible for ongoing consultation. -
Q: How is the system shipped and installed?
A> We adopt a modular design to facilitate shipping in containers. Our engineers can provide supervision for on-site assembly and commissioning, ensuring a smooth start-up. -
Q: Can you provide references or case studies from similar applications?
A> Certainly. As an established manufacturer with a global export footprint, we have numerous successful project references. We can share relevant case studies upon request under a confidentiality agreement.
