As a leading manufacturer with over 8 years of expertise in industrial processing equipment, Qingdao Conqinphi Environmental Technology Group is proud to present our advanced Multi-Effect Evaporator engineered specifically for the demanding concentration processes in the dairy and sugar industries. Our evaporators are designed to transform your liquid products into high-value concentrates with maximum energy efficiency and product quality preservation. With a modern factory spanning up to 30,000 square meters and a dedicated team of over 200 professionals, we build robust systems that form the reliable heart of your production line. We understand that concentration is a critical step where product integrity and operational cost meet; our solution is engineered to excel at both.
The core principle of our Multi-Effect Evaporator is the intelligent reuse of energy. Unlike single-effect systems, our design utilizes the vapor generated in one effect as the heating source for the next, dramatically reducing steam consumption and operational costs. This is particularly crucial in energy-intensive industries like dairy and sugar processing. We achieve this through a sophisticated arrangement of heat exchangers, separators, and condensers, all constructed from high-grade stainless steel to meet stringent food safety and hygiene standards.
Key Technical Features & Design Advantages:
- Superior Energy Efficiency: By cascading thermal energy across multiple effects (typically 2 to 5 effects), our system can achieve Steam Economy ratios significantly higher than traditional evaporators, often saving 50-70% on steam costs.
- Gentle Product Treatment: The system operates under vacuum conditions, which lowers the boiling point of the product. This is essential for heat-sensitive substances like milk proteins and sugars, minimizing thermal degradation, caramelization, and fouling, thereby preserving flavor, color, and nutritional value.
- Flexible Configuration: We offer both forward feed and mixed feed flow patterns to optimize for different product viscosities and concentration ratios. The system can be tailored for final Total Solids (TS) content as required by your specific application.
- Advanced Automation & Control: Integrated PLC control panels allow for precise regulation of temperature, pressure, flow rates, and density. This ensures consistent product quality, reduces manual intervention, and provides comprehensive data logging for batch tracking and quality assurance.
- Robust Construction & Hygiene: All product-contact surfaces are made from AISI 304 or 316L stainless steel, with polished welds and CIP (Clean-in-Place) capabilities designed to meet HACCP and other global food safety protocols.
- Comprehensive Documentation: Every major component, especially pressure vessels and piping, is supplied with a complete Mill Test Report (MTR). This traceable documentation verifies material grade, mechanical properties, and chemical composition, which is vital for quality audits and regulatory compliance.
Detailed Technical Specifications (Typical Range):
| Parameter | Specification / Range |
| Number of Effects | 2, 3, 4, or 5 Effects (Customizable) |
| Evaporation Capacity | From 500 kg/hr to 20,000 kg/hr water evaporation |
| Final Product Concentration | Dairy: Up to 50-60% TS; Sugar: Up to 70-75° Brix |
| Operating Pressure | Vacuum Operation (Typical range: 0.85 to 0.95 bar abs) |
| Heating Medium | Saturated Steam (Pressure customizable) or Thermal Oil |
| Material of Construction (Wetted Parts) | AISI 304 / 316L Stainless Steel |
| Control System | PLC with Touch Screen HMI, Optional SCADA Integration |
| Utility Requirements | Steam, Cooling Water, Electricity, CIP System |
Tangible Benefits for Your Business:
- Substantial Cost Reduction: The multi-effect design directly translates into lower utility bills, offering a rapid return on investment.
- Enhanced Product Quality: Gentle evaporation preserves the functional and organoleptic properties of dairy and sugar products, giving you a competitive edge in the market.
- Increased Production Reliability: The robust design and automated controls minimize downtime and ensure stable, continuous operation.
- Regulatory Compliance & Traceability: With full Mill Test Reports and design adherence to food-grade standards, our equipment simplifies your compliance with international food safety regulations.
- Scalability: Our systems are modular and can be designed to scale with your growing production needs.
Choosing Qingdao Conqinphi means partnering with a manufacturer that has a proven global footprint, supplying to markets across North America, Europe, Asia, Africa, and Oceania. Our annual export value of US$10-50 million underscores our reliability and the trust placed in us by international clients. Backed by a comprehensive quality management system and relevant industry certifications, we ensure every evaporator is built to last and perform. Let us provide you with a detailed engineering proposal and show you how our Multi-Effect Evaporator can optimize your concentration process, reduce your operational costs, and elevate your final product quality. Contact our technical sales team today for a consultation.
Frequently Asked Questions (FAQ):
Q1: What is the main advantage of a multi-effect evaporator over a single-effect one for my dairy plant?
A: The primary advantage is dramatic energy savings. A multi-effect system reuses the vapor from one stage to heat the next, reducing steam consumption by up to 70% compared to a single-effect unit. This significantly lowers your operating costs, which is a major factor in energy-intensive concentration processes.
Q2: Can this evaporator handle both dairy and sugar products? Won't there be cross-contamination?
A: While the core technology is suitable for both, we strongly recommend dedicated systems for different product categories to avoid any cross-contamination risk. Our design is highly adaptable, and we can engineer a system optimized specifically for your product—whether it's milk, whey, juice, or sugar syrup—ensuring hygiene and product-specific performance.
Q3: What does "Mill Test Report Provided" mean, and why is it important?
A: A Mill Test Report (MTR) is a certified document from the steel mill that details the chemical composition and mechanical properties of the stainless steel plates, tubes, and forgings used in your evaporator. It provides traceability and proof that the materials meet the specified food-grade standards (like AISI 304/316L), which is crucial for safety audits, quality assurance, and regulatory compliance in the food industry.
Q4: How is the cleaning process managed? Is it manual or automated?
A: Our systems are designed for efficient hygiene. We integrate Clean-in-Place (CIP) systems that allow for automated cleaning cycles without major disassembly. The piping, valves, and vessel internals are designed for high flow rates and complete drainage to ensure effective cleaning and sanitation, meeting the strict requirements of dairy and sugar processing.
Q5: What level of automation is included in the standard package?
A: The standard package includes a PLC-based control system with a user-friendly touch-screen HMI (Human-Machine Interface). It controls and monitors key parameters like temperatures, pressures, levels, and product density. For more advanced integration, we offer options to connect with plant-wide SCADA or MES systems.
Q6: Do you provide installation and commissioning support?
A: Yes, we provide comprehensive support. This typically includes detailed installation drawings and manuals, on-site supervision by our engineers for critical installation phases, and full commissioning services to ensure the system starts up correctly and operators are trained. The scope can be tailored to your specific needs and location.
Q7: What is the typical lead time for such a custom evaporator system?
A: Lead time depends on the complexity, capacity, and configuration of the system. For standard medium-capacity designs, it generally ranges from 16 to 24 weeks from order confirmation to ex-works readiness. We provide a precise timeline during the project quotation phase.
Q8: Can the system be designed for a specific final concentration or total solids percentage?
A: Absolutely. The system design, including the number of effects, heat exchanger surface areas, and vacuum levels, is meticulously calculated based on your feed characteristics and desired final concentration (e.g., 50% TS for milk concentrate or 75° Brix for sugar syrup). Process simulation is often used in the design phase to ensure targets are met.
