Compact MEE Unit, 2-effect Design, 304 SS, 4m² Evaporator Area, 0.3MPa Steam, 10kW, IP54 Control Box, Suitable for Small-scale Concentration

Compact MEE Unit, 2-effect Design, 304 SS, 4m² Evaporator Area, 0.3MPa Steam, 10kW, IP54 Control Box, Suitable for Small-scale Concentration photo-1

Compact MEE Unit, 2-effect Design, 304 SS, 4m² Evaporator Area, 0.3MPa Steam, 10kW, IP54 Control Box, Suitable for Small-scale Concentration photo-2

Compact MEE Unit, 2-effect Design, 304 SS, 4m² Evaporator Area, 0.3MPa Steam, 10kW, IP54 Control Box, Suitable for Small-scale Concentration photo-3

Compact MEE Unit, 2-effect Design, 304 SS, 4m² Evaporator Area, 0.3MPa Steam, 10kW, IP54 Control Box, Suitable for Small-scale Concentration photo-4

Compact MEE Unit, 2-effect Design, 304 SS, 4m² Evaporator Area, 0.3MPa Steam, 10kW, IP54 Control Box, Suitable for Small-scale Concentration photo-5

Product Spotlights

Compact 2-effect MEE unit built with 304 SS, 4 m² evaporator area, 10 kW power, IP54 control box. Energy-saving design reduces steam use by ~40%. Ideal for small-scale concentration of food, chemical, and pharmaceutical liquids. Factory-direct from ISO-certified manufacturer with global export experience.

US$ 5320 - 856900 MOQ: 3 Combos

Key Specifications

Get Latest Price

evaporator_area:

4 m²

steam_pressure:

0.3 MPa

power:

10 kW

Contact Supplier Request Quote Chat Now

Qingdao Conqinphi Environmental Technology Group Co., Ltd.

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

50 days

Product Details
Company Profile
Contact Us

evaporator_area 4 m²

steam_pressure 0.3 MPa

power 10 kW

material 304 Stainless Steel

design 2-effect

control_box_rating IP54

application Small-scale concentration

type MEE unit (Multiple Effect Evaporator)

Qingdao Conqinphi Environmental Technology Group Co., Ltd. — a trusted manufacturer established in 2015 with a 10,000–30,000 m² factory and annual export value exceeding US$10 million — proudly introduces our Compact MEE unit with 2-effect design, 304 SS construction, 4 m² evaporator area, 0.3 MPa steam, 10 kW, and IP54 control box. This system is engineered for small-scale concentration in food, chemical, and pharmaceutical industries, delivering exceptional energy efficiency and reliability in a footprint that fits tight spaces. Our team of 201–300 employees, backed by ISO9000, ISO14000, and HACCP certifications, ensures every unit meets rigorous quality standards. Whether you need to concentrate fruit juice, dairy, or wastewater, this compact evaporator offers a cost-effective solution with minimal installation complexity.

Key Features & Technical Specifications

2-Effect Design — Maximizes steam economy by reusing vapor from the first effect as heating medium for the second effect, reducing overall energy consumption by up to 40% compared to single-effect units.
304 Stainless Steel Construction — All wetted parts in contact with product are made of food-grade 304 SS, ensuring corrosion resistance, long service life, and compliance with sanitary standards.
4 m² Evaporator Area — Optimized for throughput of 150–300 L/h (depending on product viscosity and concentration ratio), ideal for batch or continuous small-scale operations.
Operating Steam at 0.3 MPa — Low-pressure steam requirement (saturated steam at 143°C) allows use of standard industrial boilers or even steam from cogeneration systems.
10 kW Electric Power — Primarily for control system, pumps, and auxiliary heaters; low electrical load makes it easy to integrate into existing facilities without upgrading electrical infrastructure.
IP54 Control Box — Dust-protected and splash-proof enclosure, suitable for humid or wash-down environments common in food processing plants.
Compact Footprint — Overall dimensions approximately 2500×1200×1800 mm (W×D×H), allowing placement on mezzanines or mobile skids.
Automatic Operation — PLC-based control with touchscreen interface; parameters like temperature, pressure, and liquid level are monitored and adjusted automatically.

Parameter	Value
Model	CQ-MEE-2-4
Number of Effects	2
Evaporator Area	4 m² (total heating surface)
Material of Construction	304 Stainless Steel (product contact)
Steam Pressure Required	0.3 MPa (gauge)
Power Consumption	10 kW (3-phase, 380V/50Hz)
Control Box Rating	IP54
Approx. Weight	1,200 kg
Water Evaporation Rate	Up to 150 kg/h (depending on product)

Advantages & Customer Benefits

Energy Savings: The 2-effect design reduces steam consumption by ~40% compared to single-effect, lowering operating costs significantly for small-scale producers.
Space Efficiency: The compact skid-mounted design requires minimal floor space; can be installed in areas with limited headroom.
Easy Maintenance: 304 SS construction is easy to clean and resists fouling; all heat exchanger plates (or tubes) are accessible for inspection and cleaning.
Flexible Application: Suitable for concentrating fruit juices, milk, whey, sugar solutions, herbal extracts, and industrial wastewater with low to medium viscosity.
Compliance Ready: Designed with food-grade materials and can be integrated with CIP (Clean-in-Place) systems; meets HACCP and GMP guidelines.
Reliable Components: Equipped with branded pumps (e.g., Grundfos), control valves, and Schneider electrics for long-term dependability.

At Qingdao Conqinphi Environmental Technology Group, we have been manufacturing evaporation and concentration systems since 2015. Our factory spans over 10,000 m² and employs more than 200 skilled workers and engineers. With annual export value exceeding US$10 million, we serve markets across North America, Europe, Asia, Africa, and Oceania. Our products are certified under ISO9001, ISO14000, HACCP, and other international standards (specific certifications available upon request). Every unit undergoes strict quality control and a full functional test before shipment from Qingdao Port.

We understand that small-scale operations require both efficiency and affordability. This Compact MEE unit delivers a rapid return on investment — typically within 12–18 months based on energy savings alone. Customization options such as higher effects, different materials (316L SS), or automation upgrades are available on request. Contact our sales team today to discuss your specific concentration needs and receive a detailed quotation. We offer complete after-sales support, including commissioning, spare parts, and remote technical assistance.

Frequently Asked Questions (FAQ)

Q: What types of liquids can this MEE unit concentrate?
A: It works well for aqueous solutions with low to medium viscosity, such as fruit juices, milk, whey, sugar syrups, herbal extracts, and dilute wastewater. For highly viscous or fouling-prone products, we recommend optional modifications.
Q: What is the minimum steam pressure required?
A: The unit is designed for 0.3 MPa (gauge) saturated steam. Operating at lower pressure may reduce capacity; we can adjust design for different steam conditions upon request.
Q: Does the unit come with a vacuum system?
A: Yes, it includes a vacuum pump to maintain the low boiling temperature in the last effect, enhancing energy efficiency and product quality.
Q: How is the control system configured?
A: Standard control includes a PLC with a 7-inch color touchscreen. Parameters such as evaporation temperature, vacuum, feed rate, and product density are monitored. Remote monitoring (SCADA) is optional.
Q: What certifications does the equipment have?
A: Our manufacturing facility holds ISO9001, ISO14000, HACCP, and other certifications. Specific product certificates (e.g., CE, ASME) can be provided upon request depending on the target market.
Q: Can the unit be used for heat-sensitive products?
A: Yes, the 2-effect design operates at lower temperatures (around 60–70°C in the last effect under vacuum) which helps preserve flavor, color, and nutritional value.
Q: What is the typical delivery time?
A: For standard configurations, delivery is 30–45 working days. Custom designs may take 50–60 working days. We offer expedited shipping for urgent orders.
Q: Do you provide installation and commissioning support?
A: Yes, we can send an engineer to supervise installation and commissioning at the customer's site (travel costs apply). Alternatively, we provide detailed manuals and remote guidance.
