Automatic Microwave Drying Machine – Factory Direct Supply
Improve Drying Efficiency with Intelligent Microwave Technology
The Automatic Microwave Drying Machine is designed for continuous industrial production and rapid moisture removal. Using advanced microwave heating technology, the material is heated internally and evenly, significantly reducing drying time while improving product quality and energy efficiency.
Suitable for food processing, herbs, chemicals, pharmaceuticals, agricultural products, wood, ceramics, and industrial materials.
Key Features
✔ Fully Automatic PLC Control
Intelligent operation system with automatic temperature, speed, and power adjustment for stable production.
✔ Fast Drying & Higher Productivity
Microwave energy directly penetrates materials for rapid internal heating and continuous processing.
✔ Energy Saving Technology
Compared with traditional hot air drying methods, energy consumption can be reduced while improving output efficiency.
✔ Continuous Conveyor Design
Supports automatic feeding, drying, sterilization, and discharging for large-scale industrial production.
✔ Uniform Heating
Reduces overheating and improves final product consistency.
✔ Optional Sterilization Function
Drying and sterilization can be completed simultaneously.
✔ SUS304 Stainless Steel Structure
Food-grade stainless steel body with easy cleaning and long service life.
Working Process
Material Feeding → Conveyor Transmission → Microwave Heating → Moisture Evaporation → Cooling → Automatic Discharge
The automatic control system ensures stable temperature and continuous operation.
Typical Applications
Food Drying & Sterilization
Fruit & Vegetable Processing
Herbal Extraction Materials
Pharmaceutical Ingredients
Chemical Powder Drying
Seafood Dehydration
Tea & Spice Processing
Wood & Building Materials
Agricultural Products
Why Choose Our Microwave Drying Machine?
✓ Factory Direct Supply
✓ OEM & Customized Solutions
✓ CE Optional
✓ Stable Continuous Production
✓ Professional Installation Support
✓ Global Export Experience
✓ Technical Training Available
Technical Specifications
Machine Model |
GS-20HMV |
GS-40HMV |
GS-60HMV |
GS-100HMV |
GS-200HMV |
Work Frequency |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
Rated Apparent Power |
≤25KW |
≤50KW |
≤75KW |
≤120KW |
≤240KW |
Output Power |
≥20KW |
≥40KW |
≥60KW |
≥100KW |
≥200KW |
Dehydration Capacity |
16-20kg/hour |
30-40kg/hour |
48-60kg/hour |
80-100kg/hour |
160-200kg/hour |
Work Process Temperature |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
Cooling Type |
Water Cool/Air Cool |
Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool |
Work Time |
24h Continuously Work |
24h Continuously Work | 24h Continuously Work | 24h Continuously Work | 24h Continuously Work |
Operation |
PLC & Touch Screen |
PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen |
Feeding Inlet Height |
40-100mm |
40-100mm | 40-100mm | 40-100mm | 40-100mm |
Belt Height |
60-1000mm |
60-1000mm | 60-1000mm | 60-1000mm | 60-1000mm |
Belt Running Speed |
0-4.5m/min or Customized |
0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized |
Belt Width |
500±100mm |
800±100mm |
800±100mm |
1000±100mm |
1200±100mm |
Belt Material |
Teflon Material or Customized |
Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized |
Size |
8640×1220×2200mm |
10960×1500×2200mm |
13200×1500×2200mm |
15600×1700×2200mm |
22560×1900×2200mm |
Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request.
FAQ
Q1: Can the machine support customized capacity?
A: Yes. Power, belt width, output, and chamber length can all be customized.
Q2: Is microwave drying suitable for heat-sensitive products?
A: Yes. Microwave drying enables shorter processing time and helps maintain product quality.
Q3: Do you provide installation and commissioning?
A: Remote guidance and overseas technical support options are available.
