Woodward 9907-1197 Speed controller
The 2301D is a microprocessor-based, all-digital controller designed to replace the earlier 2301A analog model, offering higher precision and configuration flexibility.
**Speed Control:** Precisely controls the speed of the prime mover (diesel engine, gas turbine, or steam turbine), supporting both isochronous and drop modes.
**Load Sharing:** Automatically balances the active load among generators in multi-generator grid-connected environments, ensuring system stability.
**Soft Load Transfer:** Smoothly increases or decreases the load during grid connection or disconnection, avoiding severe impacts on the power grid.
**Dual Dynamics:** Allows setting two different sets of PID dynamic parameters for different operating states (e.g., no-load and full-load) to achieve optimal control response.
Digital configuration: Compared to analog models that require knob adjustments, the 9907-1197 allows for more precise computer parameter settings via Woodward's Watch Window software, enabling more accurate adjustments.
Email: xmxblynn@163.com
Phone: +86 18059884797
This model is widely used in applications requiring high-reliability power control: Diesel/Gas Generator Sets: Used for single-unit speed regulation or multi-unit parallel operation, commonly found in data center backup power supplies, hospital emergency power supplies, etc. Marine Propulsion and Power Systems: Responsible for speed regulation and load balancing of marine main and auxiliary engines. Industrial Pump/Compressor Drives: Controls steam turbines or engines to drive large industrial equipment. Remote Power Stations: Serves as the core control unit in small power plants in remote areas.
Key Technical Parameters (Reference) Parameter Description Operating Power Supply 24 VDC (typical range 18–40 VDC) Actuator Output 4–20 mA, 0–20 mA or 0–200 mA (configurable) Speed Sensor Magnetoelectric Speed Probe (MPU) Communication Interface RS-232 Serial Port (for computer debugging) Ambient Temperature -40°C to +70°C
